Bourns Shielded Wirewound Surface Mount Inductor with Ferrite Core 4.7 μH ±20% 3.1 A Idc Q:15 SRN5040

Bourns SRN5040 Shielded Wirewound Surface Mount Inductor is designed with a ferrite core and semi-shielded wirewound construction, offering an inductance of 4.7 μH with a tolerance of ±20%. This surface mount inductor supports a maximum DC current of 3.1 A, enabling efficient power handling in compact electronic assemblies.

Its 5040 package measures 5mm in length, 4mm in height, and 5mm in depth, making it ideal for high-density PCB layouts. The solder termination style facilitates reliable mounting and electrical connection.

Operating temperature ranges from -40°C to 125°C, allowing the inductor to perform reliably under varied environmental conditions. With a low maximum DC resistance of 35 mΩ and a high self-resonant frequency of 27 MHz, this inductor minimizes power loss and maintains signal integrity.

The SRN5040 series is RoHS compliant and moulded for enhanced mechanical strength, suitable for demanding industrial and consumer applications.

Applications include DC/DC converters, notebook computers, digital video cameras, hard disk drives, mobile phones, televisions, and LCD displays, where compact inductors with stable electrical characteristics are essential.

The inductors feature a ferrite core and semi-shielded wirewound construction. Rated for operation between -40°C and 125°C. Compact 5040 package size with dimensions: 5mm length, 4mm height, and 5mm depth. Low maximum DC resistance of 35mΩ for efficient performance.

Suitable for applications in DC/DC converters, notebooks, digital video cameras, HDDs, cellphones, televisions, and LCD displays. Termination style is solder, optimized for surface mount assembly. RoHS compliant and moulded construction ensures durability.

Maximum self-resonant frequency of 27 MHz with a minimum quality factor of 15. Explore a wide choice of Surface Mount Inductors on EnvMart for your electronic component sourcing needs.
