Weidmüller BL Series Pluggable Terminal Block, 10-Contact, 3.5 mm Pitch, 1 Row, 12A Current, 320V, Polybutylene 1638630000
Specifications
| Country of Origin | Germany |
|---|---|
| Voltage | 320V |
| Brand | Weidmüller |
| Colour | Orange |
| Current | 12A |
| Depth | 14.6mm |
| Width | 22.45mm |
| Housing Material | Polybutylene Terephthalate |
| Series | BL |
| Number of Rows | 1 |
| Pitch | 3.5mm |
| Number of Contacts | 10 |
| Connector Gender | Male |
| Minimum Wire Size mm² | 0.08mm² |
| Maximum Wire Size mm² | 2.5mm² |
| Minimum Wire Size AWG | 28AWG |
| Maximum Wire Size AWG | 14AWG |
| Wire Connection Method | Screw |
Key Features
- Constructed with polybutylene terephthalate housing for durability and insulation.
- Supports a maximum current of 12A and voltage rating of 320V.
- Screw-type wire connection ensures secure and reliable contacts.
- Suitable for wire sizes ranging from 0.08 mm² to 2.5 mm² (28 AWG to 14 AWG).
- Compact dimensions with 22.45 mm width and 14.6 mm depth for space-saving PCB mounting.
- Orange color coding enhances easy identification during installation.
- Built with hardened, zinc-chromed plated clamping yoke steel for strong wire retention.
- Designed for industrial and electronic PCB applications with vertical or horizontal headers.
Product Description
Weidmüller 1638630000 BL Series pluggable terminal block is a specialized electrical component designed for efficient, reliable wiring connections in industrial, electronic, and manufacturing applications. Featuring 10 contacts arranged in a single row with a 3.5 mm pitch, this terminal block supports a rated current of 12A and voltage up to 320V.
The housing is made from high-quality polybutylene terephthalate, providing excellent insulation and durability. The screw connection method with hardened, zinc-chromed plated clamping yokes ensures secure wire retention with easy wiring. It accommodates wire sizes ranging from 0.08 mm² to 2.5 mm² (28 AWG to 14 AWG), making it versatile for various cable types.
Its compact design with a width of 22.45 mm and depth of 14.6 mm facilitates space-saving installation on PCBs. The orange color coding simplifies identification during assembly and maintenance processes. The terminal block complies with UL94 V-0 flammability standards, ensuring safety in demanding conditions.
This product is part of the BL series and is made in Germany, reflecting its high manufacturing quality and reliability in industrial electrical distribution, control panels, and automation systems. The design includes compatibility with mating headers (stock numbers 171-499 for 180° and 171-578 for 90° orientations) enabling flexible installation options.
Constructed with polybutylene terephthalate housing for durability and insulation. Supports 12A current capacity and 320V voltage rating. Screw-type wire connection for secure contacts. Accommodates wire sizes 0.08 mm² to 2.5 mm² (28 AWG to 14 AWG).
Compact dimensions: 22.45 mm width, 14.6 mm depth. Clamping yoke steel is hardened and zinc-chromed plated. Compatible with vertical/horizontal PCB mounting and mating headers. UL94 V-0 flammability classification. Ideal for industrial, electrical, and automation applications.
Made in Germany for guaranteed quality. Explore the full range of Weidmüller Pluggable Terminal Blocks and related electrical connectors at EnvMart for your industrial and automation needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
It supports a maximum current of 12A and a voltage rating of 320V.
This model has a width of 22.45 mm and a depth of 14.6 mm, making it suitable for compact PCB mounting.
It can accommodate wire sizes ranging from 0.08 mm² to 2.5 mm² (28 AWG to 14 AWG).
The housing is constructed from polybutylene terephthalate, providing durability and insulation.
This model features 10 contacts arranged in a single row.
It uses a screw-type wire connection method for secure and reliable contacts.
The terminal block features orange color coding, which enhances easy identification during installation.
The contacts are arranged with a pitch of 3.5 mm.
This product is made in Germany, reflecting its manufacturing quality.
It complies with UL94 V-0 flammability standards, ensuring safety in demanding conditions.
It is designed for industrial, electronic, and manufacturing applications, particularly in PCB installations.
