Eaton xEffect Miniature Circuit Breaker 2-Pole 10A Type B 415V AC 48V DC 10kA Breaking Capacity 132702 FAZ-B10/2-NA
Specifications
| Country of Origin | India |
|---|---|
| Range | xEffect |
| Brand | Eaton |
| Model | 132702 FAZ-B10/2-NA |
| Depth | 80mm |
| IP Rating | IP20 |
| Width | 66mm |
| Mount Type | DIN Rail |
| Current Rating | 10A |
| Series | FAZ |
| Terminal type | Screw |
| Breaking Capacity | 10kA |
| Number of Poles | 2 |
| Rated AC Voltage | 415V ac |
| Rated DC Voltage | 48V dc |
| Tripping Characteristics | Type B |
| Tripping Mechanism | Thermal Magnetic |
| Reset Actuator Type | Toggle Switch |
| Break Time | Instantaneous |
| MCB Module widths | 1P 17.5mm, 2P 35mm and 3P 52.5mm |
Key Features
- The device is a 2-pole miniature circuit breaker rated at 10A current.
- Features Type B tripping characteristics suitable for general applications.
- Supports rated voltages of 415V AC and 48V DC for versatile usage.
- Offers a breaking capacity of 10kA for high fault current interruption.
- Designed for DIN rail mounting with a compact width of 35mm for 2 poles.
- Equipped with a thermal magnetic tripping mechanism and toggle switch for reset.
- Front toggle switch clearly indicates contact position.
- Complies with IEC 898, BS EN 60898, and EN 50022/DIN 46277-3 standards.
Product Description
Eaton 132702 FAZ-B10/2-NA Miniature Circuit Breaker is a high-performance 2-pole device designed to protect electrical circuits in industrial, commercial, and residential applications. It provides both thermal and magnetic protection against overloads and short circuits, ensuring safety and reliability.
Rated for 10A current, this circuit breaker supports up to 415V ac and 48V dc voltages, with a breaking capacity of 10kA, making it suitable for a wide range of electrical distribution boards and control circuits. It features a compact design with a 35mm width for 2 poles, suitable for DIN rail mounting allowing easy installation and space saving in panels.
The FAZ series is recognized for its fast short-circuit interruption capacity that limits damage to downstream equipment by reducing let-through energy. The toggle switch provides clear contact position visibility, and its trip-free design prevents override of the safety mechanism, enhancing protection.
The breaker is constructed to comply with stringent international standards including IEC 898, BS EN 60898, and DIN 46277-3, ensuring quality and compliance in various jurisdictions. Additionally, the device is finger proof with an IP20 rating, adding an extra layer of safety for operators.
Thermal-magnetic protection for fast overcurrent interruption. Suitable for industrial, laboratory, HVAC, manufacturing, and commercial electrical systems. Compact and modular design saves panel space and installation time.
Durable screw terminal type for secure electrical connections. Mounts easily on standard DIN rails for flexible deployment. Comprehensive compliance with international electrical standards. Includes trip-free mechanism to prevent bypassing of protection.
Clear visual indication of breaker status via front toggle switch. Offers a reliable solution for circuit protection with consistent performance.
This Eaton Miniature Circuit Breaker is ideal for electrical distribution and control applications requiring reliable overload and short-circuit protection. Explore more electrical protection devices and Eaton products on EnvMart to ensure safety and durability in your electrical installations.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The current rating of this miniature circuit breaker is 10A.
It supports rated voltages of 415V AC and 48V DC.
This model has a breaking capacity of 10kA.
It features a thermal magnetic tripping mechanism.
It is designed for DIN rail mounting, which allows for easy installation.
The dimensions are 80mm in depth and 66mm in width.
It is equipped with screw terminals for secure electrical connections.
It has Type B tripping characteristics suitable for general applications.
The device has an IP20 rating, indicating it is finger-proof.
It complies with IEC 898, BS EN 60898, and DIN 46277-3 standards.
The width of this model is 35mm for 2 poles.
It is suitable for industrial, laboratory, HVAC, manufacturing, and commercial electrical systems.
