HY Electronic Corp 20 V 3 A Surface Mount Schottky Barrier Rectifier Diode DO-214AA SS32B
Specifications
| Country of Origin | China |
|---|---|
| Brand | HY Electronic Corp |
| Height | 2.23mm |
| Length | 4.7mm |
| Model | SS32B |
| Width | 3.94mm |
| Mount Type | Surface |
| Series | SS32B thru SS310B |
| Maximum Operating Temperature | 150°C |
| Package Type | DO-214AA (SMB) |
| Minimum Operating Temperature | -55°C |
| Polarity | indicated by cathode band |
| Standards/Approvals | UL 94V-0 |
| Pin Count | 2 |
| Maximum Continuous Forward Current If | 3A |
| Peak Reverse Repetitive Voltage Vrrm | 20V |
| Diode Configuration | Single |
| Rectifier Type | Schottky |
| Peak Reverse Current Ir | 20mA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 80A |
| Maximum Forward Voltage Vf | 550mV |
| Moulded Plastic Case (Plastic | flammability classification UL 94V-0) |
Key Features
- Features a DO-214AA (SMB) plastic package with UL 94V-0 flame retardant classification.
- Low forward voltage drop rated at maximum 550 mV ensuring efficient rectification.
- Operates reliably between -55°C and 150°C maximum operating temperatures.
- Designed with a metal-semiconductor junction and epitaxial construction for superior performance.
- 2-pin configuration with polarity identified by cathode marking ensures proper circuit assembly.
- Peak non-repetitive forward surge current capability of 80 A for transient handling.
- Meets industry standards suitable for applications in free-wheeling, inverters, and polarity protection circuits.
Product Description
HY Electronic Corp SS32B is a durable surface mount Schottky barrier rectifier diode designed for efficient power management in electronic circuits. Packaged in a DO-214AA (SMB) moulded plastic case with UL 94V-0 flame retardant rating, this diode provides excellent reliability and safety in high-performance applications.
With a peak reverse voltage of 20 V and a maximum continuous forward current of 3 A, the SS32B efficiently manages current flow with a low forward voltage drop of 550 mV, minimizing power losses. Its robust construction features metal-semiconductor junction with guarding and epitaxial layers that enhance response and durability.
The diode supports a wide temperature range from -55°C minimum to 150°C maximum operating temperature, making it suitable for demanding industrial environments. It withstands peak non-repetitive forward surge currents up to 80 A, ensuring resilience to transient spikes common in power electronics.
The 2-pin surface mount design and clear polarity indication via cathode band streamline the integration process on circuit boards. Applications include free-wheeling diodes in inductive loads, inverters, and polarity protection in diverse electrical and electronic systems.
DO-214AA (SMB) surface mount package with UL 94V-0 flammability rating. Maximum continuous forward current: 3 A. Peak reverse repetitive voltage: 20 V. Low forward voltage drop (max 550 mV) enhances efficiency. Temperature operation: -55°C to 150°C.
Peak non-repetitive surge current: 80 A. Metal-semiconductor junction with epitaxial construction for performance. Polarity clearly marked with cathode band.
Originating from China, the SS32B diode is ideal for industrial, manufacturing, and electronic power supply applications requiring reliable Schottky rectification. Explore EnvMart for more semiconductor and Schottky diode solutions from trusted brands like HY Electronic Corp.
Explore more products in our Schottky Diodes & Rectifiers category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum continuous forward current for this model is 3 A.
The maximum forward voltage drop is rated at 550 mV.
It operates reliably between -55°C and 150°C.
The diode is packaged in a DO-214AA (SMB) moulded plastic case.
Polarity is indicated by a cathode band on the diode.
The peak non-repetitive forward surge current capability is 80 A.
It features a metal-semiconductor junction with epitaxial construction.
The dimensions are 4.7 mm in length, 3.94 mm in width, and 2.23 mm in height.
It meets the UL 94V-0 flammability classification standards.
The diode has a 2-pin configuration.
