TRACOPOWER DIMENSION DIN Rail Power Supply Single Output 56V DC 5.4A 240W CP10.481
Specifications
| Country of Origin | India |
|---|---|
| Brand | TRACOPOWER |
| Power | 240W |
| Efficiency | 95.5% |
| Height | 124mm |
| Model | CP10.481 |
| Depth | 117mm |
| IP Rating | IP20 |
| Width | 117mm |
| Series | DIMENSION |
| Output Current | 5.4A |
| Maximum Operating Temperature | 70°C |
| Minimum Operating Temperature | -25°C |
| Number of outputs | 1 |
| Maximum Input Voltage | 240V ac |
| Electrical Phase | 1 |
| Hazardous Area Certification | IECEx, ATEX |
| Standards/Approvals | GL, IECEX ATEX, CE, CSA, cULus |
| Maximum Output Voltage | 56V dc |
| Minimum Input Voltage | 100V ac |
Key Features
- Offers high efficiency up to 95.5% ensuring low energy loss.
- Input voltage operates from 100V AC to 240V AC with active power factor correction.
- Compact dimensions of 124mm height, 117mm width, and 117mm depth.
- Operating temperature range from -25°C to 70°C for versatile environments.
- Equipped with DC-OK relay contact for operational status monitoring.
- Features remote on/off functionality for flexible control.
- Designed with minimal inrush current surge to protect electrical circuits.
- Complies with IECEx, ATEX hazardous area certifications and multiple global standards.
Product Description
PULS CP10.481 DIN Rail Power Supply is a compact and high-efficiency single output switching power supply designed for industrial, communication, instrumentation, and control applications.
This unit provides a maximum output voltage of 56V DC at a continuous current of 5.4A with an overall power rating of 240W. It supports an AC input voltage range of 100V to 240V with active power factor correction to improve energy efficiency, achieving up to 95.5% efficiency.
The power supply features a robust design with protections including overload, short circuit, and overvoltage safeguards. It has a small footprint with dimensions of 124mm height, 117mm width, and 117mm depth, making it suitable for space-constrained DIN rail mounting setups.
Operating across a broad temperature range from -25°C to 70°C, it maintains reliable performance in harsh industrial environments. Additional features include DC-OK relay contact for system monitoring, remote on/off switching, and minimal inrush current, which extends the life of electrical components in the system.
Certified to international standards such as IECEx and ATEX for hazardous locations, as well as CE, CSA, and cULus listings, this power supply ensures compliance and safety in rigorous industrial applications.
Offers high efficiency up to 95.5% ensuring low energy loss. Input voltage operates from 100V AC to 240V AC with active power factor correction. Compact dimensions of 124mm height, 117mm width, and 117mm depth. Operating temperature range from -25°C to 70°C for versatile environments.
Equipped with DC-OK relay contact for operational status monitoring. Features remote on/off functionality for flexible control. Designed with minimal inrush current surge to protect electrical circuits. Complies with IECEx, ATEX hazardous area certifications and multiple global standards.
IP20 rated enclosure providing basic protection against solid objects.
This PULS DIMENSION series power supply is well-suited for use in industrial control systems, communication equipment, office electronics, and instrumentation requiring stable DC power.
Explore more DIN Rail power supply options and accessories in the Electronics & Electricals category at EnvMart.
Explore more products in our Electronic Components, Power & Connectors category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum output voltage of this model is 56V DC.
This unit has a power rating of 240W.
The operating temperature range is from -25°C to 70°C.
The dimensions are 124mm in height, 117mm in width, and 117mm in depth.
It operates with an input voltage range from 100V AC to 240V AC.
Yes, it complies with IECEx and ATEX hazardous area certifications.
It is equipped with a DC-OK relay contact for operational status monitoring.
It features remote on/off functionality for flexible control.
This unit includes protections against overload, short circuit, and overvoltage.
The power supply has an IP20 rating, providing basic protection against solid objects.
It operates on a single electrical phase.
