EOZ FL Series Illuminated Push Button Switch Panel Mount Momentary SPST Red Green LED 13.5 mm Cutout FL13DRG5



Category Push Button Switch Brand EOZ Condition New

Specifications

Country of Origin	France
Brand	EOZ
Operating Temperature Range	-40 to +85°C
Model	FL13DRG5
IP Rating	IP67
Mount Type	Panel
Panel Thickness	1 mm to 6 mm
Ingress Protection	IP67
Series	FL
Maximum Operating Temperature	85°C
Contact Configuration	SPST
Switch Configuration	Momentary
Minimum Operating Temperature	-40°C
Panel Cutout Size	13.5 mm
Terminal type	Plug-In
Standards/Approvals	RoHS
LED Colour	Red, Green
Switch Operation	Momentary
Actuator Colour	White
Actuator Style	Cap
Switch Contact Current	65mA
Contact terminals	Gold plated nickel
LED terminals	Silver plated nickel

Key Features

The entire front cap is illuminated using pre-installed 5 V LEDs for clear visibility.
The switch features a momentary SPST operation suitable for control panel applications.
Designed for industrial use with an IP67 rating for water and dust resistance.
Constructed to fit industry standard 13.5 mm panel cutouts, compatible with panel thickness from 1 mm to 6 mm.
Gold plated nickel contact terminals and silver plated nickel LED terminals ensure reliable conductivity.
Operating temperature ranges from -40°C to +85°C supporting harsh environments.
Vandal resistant design providing enhanced durability and protection.
Plug-in terminal type (2.8 x 0.5 mm) enables easy installation and maintenance.

Product Description

EOZ FL13DRG5 FL Series Illuminated Push Button Switch is a high-quality industrial-grade switch designed for use in electrical and automation control panels. Featuring momentary operation and SPST contact configuration, this push button switch offers reliable performance and user-friendly operation with its illuminated cap that lights entirely via integrated 5 V LEDs.

The panel mount design fits the common 13.5 mm cutout sizes and accommodates panel thicknesses from 1 mm to 6 mm, making it a versatile choice for various industrial applications including manufacturing, machinery control, and automation systems.

Constructed with gold plated nickel contact terminals and silver plated nickel LED terminals, the switch ensures superior electrical conductivity and long-term durability. Its IP67 ingress protection rating guarantees resistance to dust and water, while the robust vandal resistant construction guards against mechanical damage and unauthorized tampering.

Operating reliably over a wide temperature range from -40°C to +85°C, the EOZ FL13DRG5 switch is suited for demanding industrial and outdoor environments. The plug-in terminal type enables straightforward installation and maintenance, saving time during panel assembly or field servicing.

The entire front cap illumination enhances visual indication in control panels. Momentary SPST switch operation for precise control applications. Panel mount fitting with standard 13.5 mm cutout size. Gold plated and silver plated terminals ensure dependable electrical performance.

High ingress protection rating IP67 for dust and water resistance. Wide operating temperature range from -40°C to +85°C. Vandal resistant design protects against harsh mechanical conditions. Compatible with panels 1 mm to 6 mm thick.

This switch is ideal for use in industrial automation, electrical engineering, manufacturing plants, and any application requiring a durable, illuminated momentary Push Button Switch. Explore EnvMart’s wide range of industrial switches for reliable and certified components.
