Mentor GmbH Press Fit 1-Way Straight Flexible LED Light Pipe Clear 1304.1004
Specifications
| Country of Origin | Germany |
|---|---|
| Brand | Mentor GmbH |
| Orientation | Straight |
| Length | 200mm |
| Number Of Ways | 1 |
| Mount Type | Press Fit |
| Series | Flexible Light Guide System |
| Outside diameter | 2.2mm |
| Inside Diameter | 2.2mm |
| Ambient Temperature | -40°C to +85°C |
| Standards/Approvals | UL94 |
| Flexible/Rigid | Flexible |
| Light Pipe Shape | Circular |
| Number of Light Pipes | 3 |
| Holder material | PC black UL94 |
| Light pipe material | PMMA |
Key Features
- The light pipe is flexible and has a length of 200mm for versatile applications.
- It features a circular shape with a 2.2mm inside and outside diameter for consistent light transmission.
- The press fit mounting design provides easy installation on PCBs with black plastic holders.
- The holder material is PC with UL94 certification, ensuring flame retardant performance.
- The light pipe material is PMMA offering excellent optical clarity and durability.
- The system is suitable for ambient temperatures ranging from -40°C to +85°C.
- This light pipe is part of the Flexible Light Guide System series made in Germany.
- It is designed to transmit light efficiently from SMD LEDs without light bleed or luminance loss.
Product Description
Mentor GmbH 1304.1004 Press Fit 1-Way Straight Flexible LED Light Pipe is engineered for precision light transmission from PCB-mounted SMD LEDs to user interfaces with minimal luminance loss and no light bleed. The product is made in Germany, featuring a flexible PMMA light pipe with a length of 200mm and a circular shape measuring 2.2mm in diameter.
This flexible light guide system includes separate mounting supports - black PC holders with UL94 certification - that enable secure, press-fit installation onto PCBs via two pins. The system supports reliable operation in ambient temperatures from -40°C up to +85°C, making it suitable for a wide range of industrial, commercial, and electronic applications.
The light pipe’s high optical clarity and durable materials make it well-suited for custom LED lighting designs where flexibility and precise light guidance are essential. Its compatibility with various mounting supports allows users to create customized LED light paths tailored to specific product requirements.
The light pipe is flexible and 200mm in length, providing adaptability in design. It has a circular cross-section with 2.2mm inside and outside diameters for uniform light transmission. The press fit mounting system uses black plastic PC holders certified to UL94 standards.
The holder material ensures flame retardancy and mechanical stability. The light pipe is made from PMMA, known for excellent light transmission and endurance. Temperature tolerance ranges from -40°C to +85°C for reliable operation across environments.
The product is manufactured in Germany, ensuring high-quality standards. The system does not include LEDs, allowing flexibility in LED choice and integration.
This press fit flexible LED Light Pipe is ideal for electronics manufacturing, industrial equipment, and instrumentation that requires precise LED light routing without luminance loss or crosstalk. It supports innovative lighting interface designs in electronics, automotive, and consumer devices.
Explore more LED lighting components and flexible light guide systems in the Electronics & Electricals category at EnvMart to find matched modules and accessories from trusted brands like Mentor GmbH.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has a length of 200mm, providing versatility for various applications.
Both the inside and outside diameters of the light pipe are 2.2mm, ensuring consistent light transmission.
It operates reliably in ambient temperatures ranging from -40°C to +85°C.
The light pipe is made from PMMA, which offers excellent optical clarity and durability.
This unit features a press fit mounting design, allowing for easy installation on PCBs.
The holder is made from black PC material and is certified to UL94 standards for flame retardancy.
The system includes three light pipes, allowing for multiple light transmission paths.
The light pipe has a circular shape, which aids in uniform light transmission.
It is part of the Flexible Light Guide System series, designed for efficient light transmission.
Yes, it is designed to transmit light efficiently from SMD LEDs, making it suitable for custom LED lighting applications.
This light pipe is manufactured in Germany, ensuring adherence to high-quality standards.
No, the light pipe system does not include LEDs, allowing for flexibility in LED choice and integration.
