Mentor GmbH PCB 1-Way Straight Flexible LED Light Pipe Clear Yellow 150mm 1216.1001
Specifications
| Country of Origin | Germany |
|---|---|
| Brand | Mentor GmbH |
| Orientation | Straight |
| Length | 150mm |
| Number Of Ways | 1 |
| Mount Type | PCB |
| Housing | PC black UL94 |
| Outside diameter | 5mm |
| Inside Diameter | 2.2mm |
| Lens | PC clear UL94 |
| Ambient Temperature | -40°C to +85°C |
| Standards/Approvals | RoHS |
| LED Colour | Yellow |
| Flexible/Rigid | Flexible |
| Light Pipe Shape | Round |
| Number of Light Pipes | 1 |
| Configuration Rows x Columns | 1 x 1 |
| Light pipe | PMMA |
Key Features
- The flexible light pipe is 150mm in length with a straight orientation.
- Comprises a single 1-way round light pipe with a 2.2mm inside diameter and 5mm outside diameter.
- Constructed with a clear PC lens and PMMA light pipe materials ensuring durability.
- Housing is made of black PC with UL94 flame retardant rating.
- Designed for use with surface mount (SMD) TOPLED LEDs without the LED included.
- Supports ambient temperatures from -40°C to +85°C suitable for varied conditions.
- Mounts securely on PCBs using two press-in lugs for easy installation.
- RoHS compliant ensuring adherence to environmental standards.
Product Description
Mentor GmbH 1216.1001 PCB 1-Way Straight Flexible LED Light Pipe Clear Yellow 150mm is engineered for precise light transmission from PCB-mounted LEDs to the user interface with minimal luminance loss and no light bleed.
This flexible light pipe assembly consists of a PC housing, PMMA light pipe, and a clear PC lens rated UL94 for flame resistance. The round head light pipe has an inside diameter of 2.2mm and an outside diameter of 5mm, facilitating effective light guidance in compact PCB layouts.
The product is designed to be mounted via two press-in lugs, enabling horizontal or vertical installation. Its flexibility provides design alternatives over rigid versions, suitable for various industrial electronic applications including displays, indicators, and control panels.
Operating reliably within ambient temperatures from -40°C to +85°C, it is ideal for diverse environmental conditions. The light pipe is optimized for SMD TOPLED LEDs but does not include the LED itself. Being RoHS compliant, it aligns with current environmental safety directives.
The flexible design allows easy routing of light signals on printed circuit boards. Clear PC lens ensures high transparency and durability under harsh environments. Black PC housing provides mechanical protection and flame resistance.
Single-way, round shape supports precise and targeted light output. Efficient mounting via integrated press-in lugs simplifies assembly processes. Sturdy construction sourced from Germany ensures consistent quality and performance.
This product serves well in electronic component assemblies, power connectors, LED lighting component manufacturing, and other industrial, laboratory, and commercial applications requiring effective light guidance.
Explore the extensive range of LED Light Pipes and components available in the EnvMart catalog for your precision electronic lighting needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The light pipe measures 150mm in length.
The inside diameter of the light pipe is 2.2mm, while the outside diameter is 5mm.
It operates reliably within an ambient temperature range of -40°C to +85°C.
The light pipe is constructed with a clear PC lens and PMMA light pipe materials, while the housing is made of black PC rated UL94 for flame resistance.
It mounts securely on PCBs using two press-in lugs, allowing for easy installation.
Yes, this light pipe is RoHS compliant, ensuring adherence to environmental safety standards.
It is optimized for use with surface mount (SMD) TOPLED LEDs, although the LED is not included with the product.
The light pipe has a round shape, which supports precise and targeted light output.
The configuration of this light pipe is 1 row by 1 column, indicating a single light pipe design.
This product is manufactured in Germany.
It is suitable for various industrial electronic applications, including displays, indicators, and control panels.
The housing is made of black PC with a UL94 flame retardant rating.
