Pepperl + Fuchs Block Inductive Proximity Sensor , M20 x 1.5 Thread, NPN Output, 30 V DC, 200mA, 15 mm Detection NBB15-U1-E0

Pepperl + Fuchs NBB15-U1-E0 Block Inductive Proximity Sensor is a high-performance sensor with a threaded M20 x 1.5 mounting and a flush mount type, designed for precise object detection in industrial automation applications. It operates at a maximum DC voltage of 30 V with a 200 mA switching current and features NPN output technology, ensuring reliable signal transmission in control gear and sensor systems.

The sensor housing is constructed from robust polyamide material and rated IP69K and IP68, providing excellent protections against water, dust, and mechanical impacts. It is suitable for use under harsh operating conditions with a temperature range from -25°C to 85°C, enabling deployment in diverse environments like manufacturing plants, HVAC control, and process automation.

The sensing distance of 15 mm combined with unshielded operation allows accurate proximity detection for various industrial objects. It features a block body style with dimensions of 118 mm length, 40 mm width, and 40 mm depth, optimizing space in compact installations. The device includes integral protection circuitry against reverse polarity and short circuits, improving operational reliability.

With a maximum switching frequency of 200 Hz, the sensor supports fast and responsive detection. Certifications including CCC, CSA, UL, and IEC/EN 60497-5-2: 2007 guarantee compliance with international safety and quality standards. This product is produced in Vietnam and is ideal for integration into automated assembly lines, conveyor controls, and safety monitoring systems.

The sensor features a durable polyamide housing with high IP ratings for waterproof and dustproof performance. Its M20 x 1.5 thread size enables flush mounting in industrial equipment. Supports a maximum voltage of 30 V DC and switching current of 200 mA for reliable operation.

Operating temperature range from -25°C to 85°C suits demanding environments. Includes reverse polarity and short circuit protection for device safety. Compact block design with dimensions 118 x 40 x 40 mm fits space-limited applications.

Maximum switching frequency is 200 Hz for fast switching needs. Unshielded sensor type provides precise proximity detection at 15 mm distance. Complies with CCC, CSA, UL, and IEC/EN 60497-5-2 standards for quality assurance.

Manufactured in Vietnam with consistent industrial-grade quality. Explore the Electronics & Electricals categories for more advanced sensors and automation products at EnvMart.
