Bourns 1812 Shielded Wirewound Surface Mount Inductor with Ferrite Core 100μH ±10% 180mA Idc Q:20 CC453232
Specifications
| Country of Origin | India |
|---|---|
| Brand | Bourns |
| Height | 3.2mm |
| Length | 4.5mm |
| Model | CC453232 |
| Depth | 3.2mm |
| Packaging | Tape & Reel |
| Series | CC453232 |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -40°C |
| Core Material | Ferrite |
| Inductance | 100μH |
| Standards/Approvals | RoHS |
| Package/Case | 1812 |
| Maximum DC Current | 180mA |
| Pin Count | 2 |
| Maximum DC Resistance | 4Ω |
| Inductance Tolerance | ±10 % |
| Termination Style | Solder |
| Maximum Self Resonant Frequency | 8MHz |
| Minimum Quality Factor | 20 |
| Inductor Construction | Wirewound |
Key Features
- Compact 1812 package size ensures easy PCB integration.
- Shielded construction reduces electromagnetic interference.
- Ferrite core enhances inductance stability and performance.
- Rated for operation from -40°C to 125°C ambient temperature.
- Inductance tolerance of ±10% meets precision requirements.
- Maximum DC resistance of 4Ω for efficient current flow.
- Minimum quality factor of 20 ensures high efficiency.
- Maximum self-resonant frequency at 8MHz supports high frequency applications.
Product Description
Bourns CC453232 is a 1812 shielded wirewound surface mount inductor featuring a ferrite core with an inductance of 100μH and tolerance ±10%. Designed for use in electronic and electrical applications, this inductor supports a maximum DC current of 180mA and a maximum operating temperature of 125°C.
The shielded construction minimizes electromagnetic interference, ensuring stable performance in circuit designs. The ferrite core material aids in achieving higher inductance values with improved stability across temperature variations.
This inductor measures 4.5mm in length, 3.2mm in height, and 3.2mm in depth, with a compact 1812 package/case style suitable for dense PCB layouts. It features solder terminations for secure mounting and is molded for durability.
Key electrical characteristics include a maximum DC resistance of 4Ω, minimum quality factor of 20, and a maximum self-resonant frequency of 8MHz, making it ideal for use in mobile phones, cellular phones, various consumer electronics like CTV and VCR, and other high-frequency power circuits.
The component operates reliably across a temperature range of -40°C to +125°C and is compliant with RoHS standards, ensuring environmentally safe material composition. Product is supplied on tape and reel packaging to support high-volume automated assembly processes.
Applications include power line filtering, noise suppression, DC-DC converters, and signal conditioning in industrial, commercial, and consumer electronics manufacturing. Compact 1812 surface mount package size. Shielded wirewound construction ensures EMI reduction.
Ferrite core supports stable inductance values. Wide operating temperature from -40°C to 125°C. Inductance 100μH with ±10% tolerance. Rated for maximum DC current of 180mA. Minimum quality factor of 20 at specified frequency.
Maximum DC resistance of 4Ω. Compliant with RoHS environmental standards. Supplied on tape and reel for automated PCB assembly. Explore the full range of Surface Mount Inductors and components at EnvMart to equip your industrial and electronics projects with reliable passive components.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The inductance value of this model is 100μH with a tolerance of ±10%.
It is rated for a maximum DC current of 180mA.
The maximum operating temperature is 125°C.
The minimum operating temperature is -40°C.
The maximum DC resistance is 4Ω.
It has a minimum quality factor of 20.
The maximum self-resonant frequency is 8MHz.
This inductor measures 4.5mm in length, 3.2mm in height, and 3.2mm in depth.
It is supplied on tape and reel for automated assembly processes.
The core material is ferrite, which enhances inductance stability and performance.
This model features solder terminations for secure mounting.
Yes, it is compliant with RoHS standards, ensuring environmentally safe material composition.
