Europa Miniature Circuit Breaker 1-Pole, 63A, Type B, 400V AC, 10 kA Breaking Capacity EUC1P

Europa EUC1P Miniature Circuit Breaker, model EUC1P63B, is a 1-pole electrical protection device designed to safeguard electrical circuits by interrupting fault currents effectively. This MCB features a current rating of 63A and utilizes Type B tripping characteristics, making it suitable for residential and light commercial electrical distribution panels operating at 400V AC.

Its 10 kA breaking capacity signifies robustness against high fault currents ensuring circuit safety. The compact design with dimensions 18mm (height), 78mm (width), and 87mm (depth) allows efficient space utilization within consumer units and distribution boards. The device mounts easily onto a 35mm DIN rail and features a tunnel terminal type that accommodates wire sizes ranging from 1mm² to 25mm².

The reset actuator is a toggle switch providing quick manual operation in case of tripping. The MCB is IP20 rated, offering protection against access to hazardous parts and solid objects larger than 12.5mm. It is constructed and tested in accordance with IEC 60898 and EN 60898 standards and carries CE and SEMKO certifications, underscoring its compliance and quality assurance for safe electrical installations.

This breaker operates reliably over a temperature range from -5° to 40°C, making it suitable for a broad range of environments in industrial, residential, and commercial applications requiring dependable circuit protection.

Designed for installation on 35mm DIN rail for easy mounting and maintenance. Rated AC voltage of 400V AC suitable for various electrical applications. Breaking capacity of 10 kA ensures reliable protection against short circuits.

Compact dimensions with 18mm height, 78mm width, and 87mm depth optimize panel space. Toggle switch reset actuator enables quick and convenient operation. Terminal type is tunnel style supporting wire sizes from 1mm² to 25mm².

IP20 rated for protection against solid objects exceeding 12.5 mm. Complies with international standards IEC 60898 and EN 60898 with CE and SEMKO approvals. Operating temperature range from -5° to 40°C for stable operation in diverse environments.

Manufactured in China ensuring standardized quality and performance. Ideal for electrical circuit protection in industrial, commercial, and residential settings, this MCB ensures safety and reliability in power distribution systems.
