Europa Miniature Circuit Breaker 1-Pole, 32A, Type B, 400V AC, 10 kA Breaking Capacity EUC1P
Specifications
| Country of Origin | China |
|---|---|
| Range | EUC1P |
| Brand | Europa |
| Height | 18mm |
| Model | EUC1P |
| Depth | 87mm |
| IP Rating | IP20 |
| Width | 78mm |
| Mount Type | DIN Rail |
| Current Rating | 32A |
| Terminal Capacity | 1mm2 to 25mm2 |
| Series | EUC1P |
| Terminal type | Tunnel |
| Breaking Capacity | 10kA |
| Number of Poles | 1 |
| Standards/Approvals | SEMKO, IEC 60898, EN 60898, CE |
| Rated AC Voltage | 400V ac |
| Tripping Characteristics | Type B |
| Reset Actuator Type | Toggle Switch |
Key Features
- Offers protection for electrical circuits by automatically switching off electrical power during faults.
- Mounted easily on a 35mm DIN rail for industrial and commercial electrical panels.
- Equipped with a toggle switch for simple manual reset and operation.
- Supports terminal capacities from 1mm² to 25mm² with tunnel-type terminals for secure connections.
- Conforms to IEC 60898 and EN 60898 standards for safety and performance.
- Rated IP20 for protection against solid objects and limited access to live parts.
- Compact dimensions of 18mm height, 78mm width, and 87mm depth fit standard consumer units.
- Allows operating temperatures from -5°C to 40°C, suitable for typical electrical environments.
Product Description
Europa EUC1P32B Miniature Circuit Breaker is a high-quality 1-pole circuit protection device engineered for 32 amps rated current and type B tripping characteristics, supporting 400V AC electrical systems with a 10 kA breaking capacity. This breaker is designed for reliable operation in industrial, commercial, and residential electrical panels.
The device is easily installed on a 35mm DIN rail, enabling quick and secure mounting. Its toggle switch reset actuator simplifies manual control, allowing straightforward reactivation after tripping.
Featuring tunnel-type terminals with a terminal capacity range from 1mm² to 25mm², the circuit breaker provides flexibility for various conductor sizes. Its compact and robust construction meets protective standards SEMKO, IEC 60898, EN 60898, and holds CE approval, ensuring compliance with international safety requirements.
The miniature circuit breaker maintains an IP20 rating, preventing ingress of solid objects larger than 12mm and blocking access to hazardous parts, making it safe for standard electrical enclosures. The product operates reliably within ambient temperatures ranging from -5° to 40°C, suitable for typical electrical environments.
With physical dimensions of 18mm height, 78mm width, and 87mm depth, the breaker fits neatly into consumer units and distribution panels, optimizing space utilization. Provides secure electrical circuit protection with type B tripping characteristics.
Supports current ratings from 6A up to 63A within the EUC1P range. Complies with international standards IEC 60898 and EN 60898, ensuring top safety and performance. Compact design ideal for residential, commercial, and industrial electrical systems.
Toggle switch reset actuator allows easy manual reset after trip events. Designed for mounting on standard 35mm DIN rail systems. Suitable for operating temperatures between -5°C and 40°C. Breaking capacity of 10 kA supports high fault current interruption capability.
Allows connection of conductors ranging from 1 mm² to 25 mm² with secure tunnel terminals.
This Europa Miniature Circuit Breaker is ideal for use in electrical panels that require reliable overload and short-circuit protection, typically found in industrial automation, commercial buildings, residential wiring systems, and HVAC installations.
For more technical details and product options, explore the range of circuit breakers and related accessories available on EnvMart. Enhance your electrical installations with robust, certified components.
