RS PRO xEffect FAZ Series Miniature Circuit Breaker, 2 Poles, 20A, Type C, 415V AC, 60V DC, 10 kA Breaking 278761 FAZ-C20/2
Specifications
| Country of Origin | India |
|---|---|
| Range | xEffect |
| Brand | RS PRO |
| Model | 278761 FAZ-C20/2 |
| Depth | 80mm |
| IP Rating | IP20 |
| Width | 36mm |
| Mount Type | DIN Rail |
| Current Rating | 20A |
| Series | FAZ |
| Terminal type | Screw |
| Breaking Capacity | 10kA |
| Number of Poles | 2 |
| Rated AC Voltage | 415V ac |
| Rated DC Voltage | 60V dc |
| Tripping Characteristics | Type C |
| Tripping Mechanism | Thermal Magnetic |
| Reset Actuator Type | Toggle Switch |
| Break Time | Instantaneous |
| Cooper Bussmann 20A T Cartridge Fuse, 14 x 51mmBrand | Cooper Bussmann |
Key Features
- The Type C tripping characteristic handles medium inrush currents effectively.
- Rated for 415V AC and 60V DC applications, ensuring versatile use in electrical systems.
- Designed for secure DIN rail mounting with a compact 36mm width and 80mm depth.
- Robust thermal magnetic tripping mechanism protects against overloads and short circuits.
- Features toggle switch reset actuator for quick and easy manual resetting.
- IP20 finger-safe terminals enhance user safety during installations and maintenance.
- Built to industrial and commercial standards, suitable for automation and switchgear assemblies.
Product Description
Eaton 278761 FAZ-C20/2 Miniature Circuit Breaker from the xEffect FAZ series is engineered for dependable electrical circuit protection in industrial and commercial environments. This 2-pole breaker with a 20A current rating provides precise and effective overload and short circuit protection featuring Type C tripping characteristics suitable for moderate inrush currents typically seen in motors and inductive loads.
Rated for operation at 415V AC and 60V DC, this breaker offers versatility across AC and DC electrical systems. The breaking capacity of 10 kA ensures safe interruption of fault currents, preventing damage to electrical installations. Designed for DIN rail mounting, it measures 36mm wide and 80mm deep, fitting standard electrical panels with screw terminals that guarantee robust and safe connections.
The thermal magnetic tripping mechanism facilitates fast tripping under fault conditions combined with a toggle switch actuator for quick manual reset. Its IP20 rating provides finger-safe terminals to enhance electrical safety for users and technicians.
This miniature circuit breaker is widely utilized within commercial switchgear, industrial automation systems, and various electrical installations requiring reliable overcurrent protection. It is engineered to meet the demands of robust electrical safety in switchgear assemblies and control panels.
The Type C characteristic enables effective handling of medium inrush currents. Breaking capacity of 10 kA ensures safe fault interruption. Supports AC voltage up to 415V and DC voltage up to 60V. Compact design facilitating DIN rail mounting and easy installation.
Thermal magnetic tripping mechanism for reliable circuit protection. Toggle switch reset actuator allows quick resetting post-tripping. IP20 rated for finger-safe terminals to enhance safety.
Suitable for use in electrical, industrial, manufacturing, and automation applications, this breaker is an essential component to ensure circuit safety and longevity. Eaton’s FAZ series guarantees high quality and compliance with industrial standards for robust circuit protection solutions.
Explore more products in our Miniature Circuit Breakers and Circuit Protection categories to find compatible equipment.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has a current rating of 20A, making it suitable for various electrical applications.
It features a breaking capacity of 10 kA, ensuring safe interruption of fault currents.
The breaker is rated for 415V AC and 60V DC applications, providing versatility in electrical systems.
It is designed for DIN rail mounting, which facilitates easy installation in standard electrical panels.
This miniature circuit breaker measures 36mm in width and 80mm in depth, allowing for compact installation.
It employs a thermal magnetic tripping mechanism, which provides reliable protection against overloads and short circuits.
This unit features Type C tripping characteristics, which effectively handle medium inrush currents typically found in motors and inductive loads.
It is equipped with screw terminals, ensuring robust and secure electrical connections during installation.
Yes, it is widely utilized in commercial switchgear and industrial automation systems, providing reliable overcurrent protection.
The FAZ-C20/2 has an IP20 rating, which indicates that it has finger-safe terminals to enhance user safety during installation and maintenance.
It features a toggle switch reset actuator, allowing for quick and easy manual resetting after tripping.
The country of origin for this circuit breaker is India, ensuring compliance with industrial standards.
