MEAN WELL Constant Current IP67 5 Output LED Driver, 143V, 72V, 100.1W, 700mA

MEAN WELL LPC-100-700 is a high-efficiency, constant current LED driver with an IP67 waterproof and dust-proof rating, suitable for demanding industrial and commercial LED lighting applications. Featuring a universal AC input voltage range from 90V to 370V AC, it delivers a maximum output power of 100.1W with driver current of 700mA distributed across 5 outputs with output voltages of 143V and 72V.

The device's enclosed configuration and screw mounting type ensure secure installation and protection against environmental hazards, while its cooling is managed through free air convection, making it reliable for extended operation between -40°C to +80°C.

Robust safety features include short circuit and overvoltage protection, and the unit demonstrates a surge immunity of 3kV and 2G anti-vibration ability, making it ideal for outdoor environments or moving signage where durability is critical.

The fully encapsulated plastic case certified with CE, CB, EN, and EAC standards offers reliable isolation and Class II power unit compliance, eliminating the need for functional grounding, increasing flexibility in installation.

This LED driver series undergoes 100% full load burn-in tests to ensure high reliability and long service life. Typical applications include LED lighting fixtures in commercial buildings, industrial plants, water treatment facilities, outdoor signage, and HVAC systems.

This driver provides constant current output for optimal LED brightness and longevity. Universal AC input allows operation in multiple voltage environments worldwide. IP67-rated enclosure protects against dust ingress and water jets, suitable for outdoor use.

Short circuit and overvoltage protection safeguard the connected LEDs and driver circuitry. High efficiency up to 90% reduces energy consumption and heat generation. Compliant with multiple international safety standards ensuring safe and certified operation.

Five independent output channels enable flexible and multi-point LED powering. Cool operation by natural convection eliminates the need for fans and reduces maintenance. Class II construction with full encapsulation for electrical safety and environmental protection.
