MEAN WELL 5 Output IP67 Rated Constant Voltage LED Driver 24V 151.2W 6.3A

MEAN WELL LPV-150-24 is a high-performance, constant voltage LED driver featuring 5 outputs rated at 24V DC and delivering maximum output power of 151.2W with 6.3A current. This LED driver is housed in a 94V-0 flame retardant plastic enclosure and provides IP67 protection, ensuring suitability for both indoor and outdoor applications where dust and moisture resistance are essential.

The LPV-150 series accepts a wide input AC voltage range from 180V to 305V, making it compatible for varied electrical environments. Its advanced design incorporates full waterproof potting with heat conductive silicone to enhance heat dissipation, enabling reliable performance in temperatures ranging from -25°C to +65°C without the need for a fan, relying on free air convection cooling.

High efficiency up to 90% reduces energy losses and heat generation. It incorporates multiple protective features, including short circuit, overload, over voltage, and over temperature protections to ensure long-term reliability and safety in demanding industrial and commercial LED lighting applications.

This LED driver supports five output voltages commonly used for LED systems: 12V, 15V, 24V, 36V, and 48V, with the LPV-150-24 model specifically providing 24V output. The terminal connection is wire type, and mounting is screw-based for secure and easy installation. Its configuration is enclosed and classified as Class II, AC-DC primary powered LED driver.

Typical use cases include indoor and outdoor LED signage, LED decorative lighting, architectural wall wash lighting, LED strips, and other constant voltage LED luminaire applications in industrial, commercial, and architectural sectors.

Features constant voltage output ideal for LED lighting applications. Built with IP67 protection for dust and moisture resistance. Supports five common DC output voltages including 24V. Utilizes high-efficiency design achieving up to 90% efficiency.

Equipped with multiple protections including short circuit and over temperature. Fanless cooling via free air convection supports operation from -25°C to +65°C. Compliant with international standards such as CE, BIS, EN, UL, and EAC.

Enclosed with flame retardant 94V-0 plastic for safety and durability. Ideal for indoor and outdoor LED signage, decorative lighting, and building illumination. Explore our range of LED drivers and lighting components to meet diverse industrial and commercial lighting needs.
