Bourns Shielded Wirewound Surface Mount Inductor 4.7 μH ±20 % 13.5 A Idc Carbonyl Powder Core 1265 Package SRP1265A

Free Delivery in India | Lowest Global Shipping Charges

Bourns Shielded Wirewound Surface Mount Inductor 4.7 μH ±20 % 13.5 A Idc Carbonyl Powder Core 1265 Package SRP1265A

Name: Bourns Shielded Wirewound Surface Mount Inductor 4.7 μH ±20 % 13.5 A Idc Carbonyl Powder Core 1265 Package SRP1265A
Brand: BOURNS
SKU: 377211
Price: 1.35 USD
Availability: InStock



Category Surface Mount Inductor Brand BOURNS Condition New

Specifications

Country of Origin	India
Brand	Bourns
Height	6.2mm
Length	13.5mm
Model	SRP1265A
Depth	12.5mm
Packaging	Reel
Series	SRP1265A
Maximum Operating Temperature	150°C
Minimum Operating Temperature	-40°C
Core Material	Carbonyl Powder
Inductance	4.7μH
Standards/Approvals	RoHS
Package/Case	1265
Maximum DC Current	13.5A
Pin Count	2
Maximum DC Resistance	8.4mΩ
Inductance Tolerance	±20 %
Termination Style	Solder
Maximum Self Resonant Frequency	17MHz
Minimum Quality Factor	20
Inductor Construction	Wirewound
Automotive Standard	AEC-Q200

Key Features

Wirewound construction ensures stable inductance and high reliability.
Carbonyl powder core provides high saturation current and low loss.
Magnetically shielded design reduces electromagnetic interference.
Rated for up to 150°C maximum operating temperature.
Complies with RoHS and is halogen-free for environmental safety.
Package size is 1265 with dimensions 13.5 mm length, 12.5 mm depth, and 6.2 mm height.
Inductance tolerance of ±20 % suitable for power supplies and DC-DC converters.
AEC-Q200 qualified for automotive system applications.

Product Description

Bourns SRP1265A is a shielded wirewound surface mount power inductor featuring a carbonyl powder core with an inductance of 4.7 μH ±20 % and a maximum DC current rating of 13.5 A. Designed for high-performance applications, it combines magnetic shielding with a wirewound construction for excellent saturation current and electrical stability.

This inductor has a compact 1265 package case with a length of 13.5 mm, depth of 12.5 mm, and height of 6.2 mm. It supports a maximum operating temperature of 150°C and a minimum of -40°C, making it reliable for harsh environments.

The SRP1265A series is RoHS compliant and halogen-free, making it suitable for environmentally-conscious designs. It holds the AEC-Q200 automotive standard certification, allowing use in automotive electronic systems such as driver assistance, infotainment, and lighting control modules.

Its low maximum DC resistance of 8.4 mΩ and a self-resonant frequency of 17 MHz contribute to efficient power conversion and filtering in DC-DC converters, power supplies, and other electronic circuits demanding high current handling and low electromagnetic interference.

The 2-pin solder termination style ensures compatibility with common surface mount assembly processes, enabling automated manufacturing. Its moulded design enhances mechanical robustness.

Wirewound construction ensures stable inductance and high reliability. Carbonyl powder core provides high saturation current and low loss. Magnetically shielded design reduces electromagnetic interference. Rated for up to 150°C maximum operating temperature.

Complies with RoHS and is halogen-free for environmental safety. Package size is 1265 with dimensions 13.5 mm length, 12.5 mm depth, and 6.2 mm height. Inductance tolerance of ±20 % suitable for power supplies and DC-DC converters.

AEC-Q200 qualified for automotive system applications. Termination style is solder with 2 pins for surface mount assembly. Maximum DC resistance is a low 8.4 mΩ for efficient current handling.

Ideal for use in industrial electronics, automotive modules, telecommunications, and power management systems. Browse the Surface Mount Inductors category on EnvMart for more high-quality power inductors and components.
