Bourns 5040 Shielded Wirewound Surface Mount Inductor 10 μH ±20 %, 2.1 A Idc, Ferrite Core SRN5040

Bourns SRN5040 Shielded Wirewound Surface Mount Inductor is a 10 μH inductance component designed with a ferrite core and semi-magnetically shielded wirewound construction. This inductor supports a maximum DC current of 2.1 A and offers reliable performance with a quality factor of 17 and a maximum self-resonant frequency of 17 MHz.

The component comes in a compact 5040 package measuring 5 mm in length, 4 mm in height, and 5 mm in depth with two pins suitable for solder termination. Its operating temperature range of -40°C to 125°C makes it suitable for diverse industrial and electronic applications.

This inductor is molded for durability and complies with RoHS standards, ensuring environmental safety. Its low DC resistance of 68 mΩ minimizes power loss, making it efficient for power supply circuits.

The SRN5040 series inductors are ideal for DC/DC converters as well as consumer electronic devices such as notebook computers, digital video equipment, hard disk drives, cellphones, televisions, and LCD display systems. The semi-shielded design improves electromagnetic interference performance for sensitive electronic circuits.

Provides inductance of 10 μH with ±20% tolerance. Supports maximum DC current of 2.1 A for reliable performance. Features ferrite core material enhancing magnetic efficiency. Compact 5040 package with 5 mm length and 4 mm height.

Wide operating temperature range from -40°C to 125°C. Low maximum DC resistance of 68 mΩ for reduced power losses. Semi-magnetically shielded construction reduces EMI. Solder termination style suitable for surface mount technology.

Molded body complying with RoHS requirements. Designed for multiple industrial and consumer electronics applications. Explore our extensive catalogue of Surface Mount Inductors for advanced electronics design and manufacturing, featuring components that meet demanding industrial specifications.
