Bourns Surface Mount Inductor 2.2 μH 2.1 A Ferrite Core 4026 Package SRN4026

Free Delivery in India | Lowest Global Shipping Charges

Bourns Surface Mount Inductor 2.2 μH 2.1 A Ferrite Core 4026 Package SRN4026

Name: Bourns Surface Mount Inductor 2.2 μH 2.1 A Ferrite Core 4026 Package SRN4026
Brand: BOURNS
SKU: 375902
Price: 0.31 USD
Availability: InStock



Category Surface Mount Inductor Brand BOURNS Condition New

Specifications

Country of Origin	India
Brand	Bourns
Height	2.5mm
Length	4mm
Model	SRN4026
Depth	4mm
Packaging	Reel
Series	SRN4026
Maximum Operating Temperature	125°C
Minimum Operating Temperature	-40°C
Core Material	Ferrite
Inductance Range	1 to 220 μH
Inductance	2.2μH
Standards/Approvals	RoHS
Package/Case	4026
Maximum DC Current	2.1A
Pin Count	2
Maximum DC Resistance	29mΩ
Inductance Tolerance	±30 %
Termination Style	Solder
Maximum Self Resonant Frequency	60MHz
Minimum Quality Factor	9
Inductor Construction	Semi Shielded

Key Features

The inductor features a 4026 package with 4 mm length, 2.5 mm height, and 4 mm depth.
It offers 2.2 μH inductance with ±30% tolerance and 2.1 A maximum DC current rating.
Constructed with a ferrite core and semi-shielded design for EMI reduction.
Operates from -40°C to 125°C and complies with RoHS environmental standards.
Maximum DC resistance is 29 mΩ, supporting efficient power usage.
Maximum self-resonant frequency is 60 MHz with a quality factor of 9 minimum.
Termination style is solder, and packaging format is reel for assembly automation.
Suitable for applications including DC/DC converters, notebooks, and consumer electronics.

Product Description

Bourns SRN4026 surface mount inductor delivers reliable inductance of 2.2 μH with a maximum DC current rating of 2.1 A. It features a semi-shielded design with a ferrite core offering effective electromagnetic interference reduction for sensitive electronic circuits.

The compact 4026 package measures 4 mm in length, 2.5 mm in height, and 4 mm in depth, making it suitable for high-density PCB layouts. The inductance tolerance is ±30%, ensuring consistent performance within expected parameters. With a maximum DC resistance of 29 mΩ, it minimizes power losses in critical power applications.

Operating temperature ranges from -40°C to 125°C, enabling usage in diverse environmental conditions. Designed with a solder termination style and supplied on reel packaging, it facilitates automated assembly processes in manufacturing.

The inductor has a maximum self-resonant frequency of 60 MHz and a minimum quality factor of 9. These characteristics support applications in DC/DC converters, notebook computers, digital video cameras, HDDs, cellphones, televisions, and LCD displays. Manufactured following RoHS standards, it is environmentally compliant.

The inductor comes with a ferrite core construction for enhanced magnetic properties. The shielded semi magnetically design improves EMI shielding and circuit integrity. Compact footprint supports use in miniaturized designs and portable electronics.

High current rating up to 2.1 A supports stable power delivery in electronic circuits. RoHS compliant ensuring reduced hazardous substances in manufacturing. Solder termination style enhances mechanical strength and electrical connectivity.

Packaged in reels for efficient component feeding during PCB assembly.

This Bourns SRN4026 inductor is a crucial component for industrial, electronic manufacturing, consumer electronics, and telecommunications applications. EnvMart offers this product for engineers and professionals seeking quality Surface Mount Inductors with trusted brand reliability.
