Phoenix Contact MKDS 5 HV/3-9.52-Z Series Straight PCB Terminal Block 3 Contacts 9.52 mm Pitch 400V 24A 1 Row 1907429

Phoenix Contact 1907429 MKDS 5 HV/3-9.52-Z Series Straight PCB Terminal Block is engineered for robust and reliable electrical connections in demanding industrial and electronic environments. This terminal block features 3 contacts with a precise 9.52 mm pitch and is designed for high voltage applications up to 400V and currents up to 24A.

The housing is made of high-quality polyamide, providing excellent insulation properties and mechanical stability. Its straight design allows for easy horizontal mounting on printed circuit boards, making it suitable for compact and efficient PCB layouts.

The MKDS 5 HV series terminal blocks offer enhanced air and creepage distances, contributing to electrical safety and compliance with UL approvals at 600 V. This is achieved via unique Z pinning technology which increases reliability in high-voltage environments.

Connection is facilitated by screw terminals compatible with a wide range of wire sizes: solid wires from 0.2 to 6 mm² and stranded wires from 0.2 to 4 mm², ensuring versatile and secure wiring options.

These terminal blocks are ideal for use in industrial automation, power distribution, and control panel assembly, providing efficient PCB wiring solutions for electrical engineers and designers.

Designed for high voltage operation up to 400V with a current rating of 24 A. Features 3 contacts arranged in a single row with a 9.52 mm pitch. Constructed with a durable polyamide housing material ensuring longevity and safety.

Straight orientation suitable for horizontal PCB mounting applications. Increased air and creepage distances compliant with 600 V UL approval through Z pinning. Supports screw connections for solid wires from 0.2 to 6 mm² and stranded wires from 0.2 to 4 mm².
