Microchip 2 kB Serial EEPROM 6-Pin SOT-23 Serial-SPI 900 ns Access Time 25AA02UIDT-I/OT

Microchip 25AA02UIDT-I/OT is a compact and reliable 2 kB Serial Electrically Erasable Programmable Read-Only Memory (EEPROM) designed for industrial and commercial semiconductor applications. Featuring a 6-pin SOT-23 surface mount package, this Serial-SPI interface EEPROM offers high-speed access with a maximum clock frequency of 10 MHz and a rapid maximum random access time of 900 ns.

The memory is organized as 256 words by 8 bits each, with memory size of 2 kB to suit embedded system storage needs. It also supports a wide operating voltage range of 1.8 V to 5.5 V, delivering flexibility across diverse power supply scenarios.

With operational temperature tolerance from -40°C up to 85°C, this device is suitable for use in a range of demanding environmental conditions typical to industrial electronics, telecommunications, instrumentation, and consumer electronics. Its data retention capability is rated at 200 years, providing long-term data reliability.

The low supply current of 5 mA adds to its energy-efficient design. The absence of automotive standards certification indicates it is optimized for non-automotive semiconductor usage.

The compact dimensions of 3.1 mm length and 3.2 mm width conform to industry-standard surface mount technology, facilitating easy automated PCB assembly.

Typical applications include industrial controls, embedded systems, data logging, configuration storage, and memory expansion in various electronics designs requiring reliable non-volatile serial memory components.

Set includes one Microchip 25AA02UIDT-I/OT Serial EEPROM device. Provides 2 kB memory size organized as 256 x 8 bits. Operates at a maximum clock frequency of 10 MHz. Supports Serial-SPI interface for seamless integration.

Operates within a wide voltage range from 1.8 V to 5.5 V. Compact surface mount SOT-23 package measuring 3.1 mm length and 3.2 mm width. Data retention of up to 200 years ensuring long-term reliability. Operating temperature range from -40°C to 85°C suitable for various environments.

Low supply current of 5 mA for energy-efficient applications. Designed without automotive certification standards. Explore more semiconductor components and memory chips at EnvMart for industrial and laboratory applications.
