Littelfuse 1-Element Uni-Directional TVS Diode 600 W 3-Pin SOT-23 SLVU2.8HTG

Free Delivery in India | Lowest Global Shipping Charges

Littelfuse 1-Element Uni-Directional TVS Diode 600 W 3-Pin SOT-23 SLVU2.8HTG

Name: Littelfuse 1-Element Uni-Directional TVS Diode 600 W 3-Pin SOT-23 SLVU2.8HTG
Brand: LITTELFUSE
SKU: 371725
Price: 0.86 USD
Availability: InStock



Category TVS Diode Brand LITTELFUSE Condition New

Specifications

Country of Origin	Thailand
Brand	Littelfuse
Height	1.02mm
Length	3.04mm
Model	SLVU2.8HTG
Width	1.4mm
Mount Type	Surface
Series	SLVU2.8
Maximum Operating Temperature	125°C
Package Type	SOT-23
Minimum Operating Temperature	-40°C
Pin Count	3
Number of Elements per Chip	1
Clamping Voltage VC	15V
Diode Configuration	Single
Direction Type	Uni-Directional
Minimum Breakdown Voltage Vbr	3V
Maximum Reverse Stand-off Voltage Vwm	2.8V
Peak Pulse Power Dissipation Pppm	600W
Maximum Peak Pulse Current Ippm	24A
Maximum Reverse Leakage Current	1μA
Diodes Inc D1213A-01SO-7, Uni-Directional TVS Diode, 3-Pin SOT-23Brand	DiodesZetex

Key Features

Single diode configuration with uni-directional direction type.
Mount type for surface mount applications in a compact SOT-23 package.
Minimum breakdown voltage of 3 V and maximum reverse stand-off voltage of 2.8 V.
Peak pulse current capability of 24 A with clamping voltage of 15 V.
Operating temperature range from -40°C to 125°C ensuring reliability in harsh environments.
Low leakage current of 1 μA maximum at 2.8 V.
Small form factor with dimensions 3.04 mm length, 1.4 mm width, and 1.02 mm height.
Provides robust ESD protection compliant with standards such as IEC61000-4-2 and IEC61000-4-5.

Product Description

Littelfuse SLVU2.8HTG is a 1-element uni-directional transient voltage suppressor (TVS) diode engineered to protect electronic circuits from voltage spikes and ESD events. With a peak pulse power dissipation of 600 W and a 3-pin SOT-23 surface mount package, it is ideal for compact circuit protection in sensitive equipment.

The diode features a minimum breakdown voltage of 3 V and a maximum reverse stand-off voltage of 2.8 V, ensuring effective clamping at 15 V under transient conditions. It is capable of withstanding peak pulse currents up to 24 A and supports ESD protection compliant with IEC standards for contact and air discharge at ±30 kV.

The device operates reliably over a wide temperature range from -40°C to 125°C, making it suitable for industrial, telecommunications, and automotive applications where surge and transient protection is critical.

Its low leakage current of 1 μA and low capacitance of approximately 2 pF per line help to minimize interference with high-speed signal lines while providing robust protection. Compact dimensions (3.04 mm length, 1.4 mm width, 1.02 mm height) and a surface mount SOT-23 package enable easy PCB integration in dense designs.

Manufactured in Thailand following stringent quality protocols, this Littelfuse TVS diode belongs to the SLVU2.8 series and supports lightning and EFT transient suppression, improving equipment durability and uptime in demanding environments.

Suitable for use in various industrial, laboratory, electronics manufacturing, and commercial applications, this diode safeguards components from transient voltage damage effectively.

Single element uni-directional diode with 600 W peak pulse power. Provides ESD protection compliant with IEC61000-4-2 and IEC61000-4-5 standards. Low leakage current and low capacitance for high-frequency systems. Compact SOT-23 surface mount package for space-saving design.

Wide operating temperature range of -40°C to 125°C. Explore related semiconductor and TVS Diode products at EnvMart for comprehensive transient voltage and ESD protection solutions.
