| Country of Origin | Japan |
|---|---|
| Brand | Murata |
| Height | 0.5mm |
| Length | 1mm |
| Model | LQW15AN6N8G00D |
| Depth | 0.6mm |
| Packaging | Paper Tape |
| Series | LQW |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Interfaces | LAN |
| Core Material | Ferrite |
| Inductance | 6.8nH |
| Standards/Approvals | RoHS |
| Package/Case | 0402 |
| Maximum DC Current | 700mA |
| Pin Count | 2 |
| Maximum DC Resistance | 90mΩ |
| Inductance Tolerance | ±2 % |
| Termination Style | Solder |
| Maximum Self Resonant Frequency | 6GHz |
| Minimum Quality Factor | 25 |
| Inductor Construction | Wirewound |
Murata LQW15AN6N8G00D is a wirewound surface mount inductor featuring a ferrite core with an inductance of 6.8 nH and a tight tolerance of ±2 %. This compact 0402 size inductor measures 1 mm in length, 0.5 mm in height, and 0.6 mm in depth, making it suitable for applications where board space is limited.
The inductor has a maximum DC current rating of 700 mA and a maximum DC resistance of 90 mΩ, providing efficient current handling capabilities. It demonstrates a high self-resonant frequency of 6 GHz and a minimum quality factor of 25, ideal for use in very high frequency (VHF) and ultra high frequency (UHF) circuits such as wireless telecommunication devices including Bluetooth, GSM, and WLAN systems.
Designed for reliability, it operates over a wide temperature range from -55°C to 125°C. The construction utilizes wirewound technology around a ferrite core, enhancing its performance for radio frequency applications. Murata's LQW15AN6N8G00D is RoHS compliant and supplied on paper tape packaging facilitating automated placement on printed circuit boards.
This inductor series is widely recognized for its high resonance frequency and low inductance tolerance, providing designers with precision and consistency. Solder termination style ensures compatibility with standard surface mount technology (SMT) assembly processes.
Compact 0402 package with precise dimensional specs. High quality wirewound construction on ferrite core. Excellent for high frequency wireless telecom circuits. Wide operating temperature range from -55°C to 125°C. Low DC resistance at 90 mΩ supporting efficient current flow.
RoHS compliant ensuring environmentally safe production. Paper tape packaging for streamlined SMT assembly. High self-resonant frequency of 6 GHz for RF applications. Minimum quality factor of 25 for signal integrity.
This Murata LQW series Surface Mount Inductor is ideal for industrial, electronic component manufacturing, telecommunications, and general electronics applications where compact, reliable, and high-frequency inductors are required. Explore more quality inductors and passive components in the Electronics & Electricals category at EnvMart.
