Bourns Wirewound Shielded Surface Mount Inductor 22 μH ±20%, 3.4 A Idc, Ferrite Core, 1060 Package SRN1060

Free Delivery in India | Lowest Global Shipping Charges

Bourns Wirewound Shielded Surface Mount Inductor 22 μH ±20%, 3.4 A Idc, Ferrite Core, 1060 Package SRN1060

Name: Bourns Wirewound Shielded Surface Mount Inductor 22 μH ±20%, 3.4 A Idc, Ferrite Core, 1060 Package SRN1060
Brand: BOURNS
SKU: 368113
Price: 0.63 USD
Availability: InStock



Category Surface Mount Inductor Brand BOURNS Condition New

Specifications

Country of Origin	India
Brand	Bourns
Height	6mm
Length	9.8mm
Model	SRN1060
Depth	10mm
Packaging	Reel
Series	SRN1060
Maximum Operating Temperature	125°C
Minimum Operating Temperature	-40°C
Core Material	Ferrite
Inductance	22μH
Standards/Approvals	RoHS
Package/Case	1060
Maximum DC Current	3.4A
Pin Count	2
Maximum DC Resistance	53mΩ
Inductance Tolerance	±20 %
Termination Style	Solder
Maximum Self Resonant Frequency	8MHz
Minimum Quality Factor	20
Inductor Construction	Wirewound

Key Features

Compact 1060 package size suitable for surface mounting.
Ferrite core enhances magnetic performance and minimizes losses.
Semi magnetically shielded wirewound construction reduces electromagnetic interference.
Maximum DC resistance of 53 mΩ ensures efficient current flow.
Operating temperature range from -40°C to 125°C supports diverse environments.
High quality factor (Q) of 20 ensures superior inductance performance.
RoHS compliant construction meets environmental standards.
Solder termination style enables reliable PCB assembly.

Product Description

Bourns SRN1060 wirewound shielded Surface Mount Inductor is designed for high performance in compact electronic circuits. Featuring a ferrite core and semi magnetically shielded construction, this inductor offers stable inductance of 22 μH with ±20% tolerance and a maximum DC current rating of 3.4 A, making it ideal for power supply filtering and energy storage.

Its 1060 package size with dimensions 9.8 mm length, 6 mm height, and 10 mm depth allows easy integration in surface mount technology (SMT) assemblies. The inductor exhibits a low DC resistance of 53 mΩ, contributing to efficient power handling and reduced heat generation.

This RoHS-compliant product is suitable for industrial, automotive, and consumer electronics applications, including DC/DC converters, notebook computers, digital video cameras, televisions, and LCD displays. The solder termination style ensures secure electrical and mechanical connections on printed circuit boards.

Notable features include a minimum operating temperature of -40°C and maximum operating temperature of 125°C, enabling reliable operation in harsh environments. With a high quality factor (Q) of 20 and a maximum self-resonant frequency of 8 MHz, it supports efficient signal integrity and filtering performance.

Compact 1060 surface mount package. Ferrite core for enhanced magnetic properties. Semi magnetically shielded to reduce EMI. Low DC resistance of 53 mΩ to minimize losses. Wide operating temperature range from -40°C to 125°C.

RoHS compliant for environmental safety. Solder termination style for reliable mounting. Maximum self-resonant frequency of 8 MHz. Quality factor of 20 ensures stable inductance. Packaged on reels for manufacturing efficiency.

This inductor is an excellent choice for industrial and electronic design engineers seeking reliable, high-performance inductors for demanding surface mount applications. Browse more high-quality inductors and electronic components in the Electronics & Electricals category at EnvMart.
