Eaton Shielded Wirewound Surface Mount Inductor with Ferrite Core 330μH ±20% 2.01A DC Current DR127-331-R

The Eaton DR127-331-R is a shielded wirewound surface mount inductor designed with a ferrite core to provide efficient magnetic performance. This inductor has an inductance of 330μH with a tolerance of ±20% and supports a maximum DC current of 2.01A, making it suitable for high power density applications.

Manufactured to operate at maximum temperatures up to 125°C, this inductor features a 0127 package size with dimensions of 12.5mm length, 8mm height, and 12.5mm depth. Its wirewound construction ensures durability and high efficiency.

This component includes shielding to minimize electromagnetic interference and has a maximum DC resistance of 574mΩ, which keeps power losses low. The termination style is surface mount with 2 pins, supplied in reel packaging for automated assembly processes.

Typical applications for the DR series inductors include use in computers, DVD players, portable electronic devices, LCD panels, DC-DC converters such as buck, boost, forward and resonant converters, as well as noise filtering and filter chokes.

Constructed with a ferrite core for optimized magnetic properties. Wirewound design provides stability and high power density. RoHS compliant and suitable for use in various electronic assemblies. Designed to handle up to 2.01A DC current with low DC resistance.

Compact 0127 package facilitates space-saving surface mount designs. Capable of operating within a temperature range from -40°C to 125°C. Shielding reduces electromagnetic interference in electronic circuits.

This Eaton inductor series is ideal for industrial applications in electronics manufacturing, telecommunications, power supplies, and consumer electronics requiring reliable high-frequency inductors.
