Eaton Non-Resettable Fuse, Radial Lead, 10A Current Rating, 125V AC, Fast Acting SR-5F-10A-BK
Specifications
| Country of Origin | China |
|---|---|
| Voltage | 125V ac |
| Diameter | 8.5mm |
| Brand | Eaton |
| Body Material | Plastic |
| Height | 8.1mm |
| Length | 7.6mm |
| Model | SR-5F-10A-BK |
| Width | 8.5mm |
| Current Rating | 10A |
| Series | SR-5F |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -40°C |
| Lead Length | 4.3mm |
| Breaking Capacity | 50A |
| Standards/Approvals | UL 4814, RoHS, UL 94V0, UL, IEC 600680, MILSTD0F |
| Lead Diameter | 0.6mm |
| Fuse Characteristics | Fast Acting |
| Lead Orientation | Radial |
Key Features
- Fast-acting fuse designed for PCB applications.
- Radial lead orientation for easy installation.
- Plastic thermoplastic polyamide body for durable performance.
- Rated breaking capacity of 50A ensuring reliable circuit protection.
- Operates within temperature range from -40°C to 125°C.
- Complies with UL 4814, RoHS, UL 94V0, IEC 600680, and MILSTD0F standards.
- Compact dimensions with length 7.6mm, width 8.5mm, and height 8.1mm.
- Lead diameter of 0.6mm and lead length of 4.3mm.
Product Description
Eaton SR-5F-10A-BK Non-Resettable Fuse is a fast-acting fuse with a radial lead design, rated for 10A current and 125V AC voltage. It features a durable plastic thermoplastic polyamide body making it suitable for various PCB fuse applications requiring fast interruption of current.
This fuse is part of the Cooper Bussmann SR-5F series, ideal for electrical protection within industrial, commercial, and home automation systems. Its compact design with a length of 7.6mm and diameter of 8.5mm allows integration in space-constrained circuits.
The fuse operates reliably within a wide temperature range from -40°C to 125°C and has a breaking capacity of 50A, providing robust protection against overcurrent conditions. Constructed to meet stringent international standards such as UL 4814, RoHS, UL 94V0, IEC 600680, and MILSTD0F, it ensures compliance and safety in demanding environments.
Fast-acting fuse designed for sensitive circuit protection. Radial lead orientation for secure and straightforward mounting. Thermoplastic polyamide body material for durability and safety. High breaking capacity of 50A supports reliable circuit interruption.
Wide operating temperature range from -40°C to 125°C. Compact form factor with precise dimensions facilitates PCB integration. Complies with multiple international compliance and safety standards. Lead diameter of 0.6mm and length of 4.3mm assures compatibility with standard connectors.
This SR-5F-10A-BK fuse is manufactured in China and branded by Eaton, a globally recognized leader in electrical protection devices, ensuring quality and reliability. Highly suited for industrial machines, electrical control panels, HVAC systems, and manufacturing equipment requiring fast and dependable fuse protection.
Explore more products in the Non Resettable Fuse category to find compatible and complementary components for your electrical safety solutions, all available at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has a current rating of 10A.
It operates at a voltage of 125V AC.
The breaking capacity of this fuse is 50A, ensuring reliable circuit protection.
The fuse has a length of 7.6mm, width of 8.5mm, and height of 8.1mm.
It features a radial lead orientation, which allows for easy installation.
This fuse operates within a temperature range of -40°C to 125°C.
The body of the fuse is made from thermoplastic polyamide, providing durability.
It complies with UL 4814, RoHS, UL 94V0, IEC 600680, and MILSTD0F standards.
The lead diameter is 0.6mm and the lead length is 4.3mm.
This fuse is part of the Cooper Bussmann SR-5F series.
It is suitable for various PCB applications requiring fast interruption of current, including industrial and commercial systems.
This fuse is manufactured in China.
