Chauvin Arnoux AC/DC Clamp Meter F405, 1500 A dc, 1700 V dc, CAT IV, CAT III P01120946

The Chauvin Arnoux F405 AC/DC Clamp Meter is a high-performance electrical testing instrument designed for precise measurement of current and voltage in demanding industrial and maintenance settings. Brand Chauvin Arnoux offers an instrument capable of handling up to 1500 A DC and voltage measurements up to 1700 V DC with CAT IV and CAT III safety levels, providing reliable and safe operation on electrical installations.

This clamp meter integrates True RMS digital acquisition technology for accurate readings on complex waveforms, making it suitable for maintenance, diagnostics, and monitoring in electrical, industrial, laboratory, and HVAC applications. Its 48 mm jaw opening accommodates a wide range of conductor sizes, enhancing versatility on-site.

The meter offers comprehensive measurement functions including AC/DC current, AC/DC voltage, resistance, diode testing, power metrics (W, var, VA, PF), phase rotation, inrush current, harmonics, frequency, and continuity. The backlit LCD display ensures readability even in dim environments, and the robust IP54 protection rating safeguards the device against dust and splashes during operation.

The F405 operates reliably in temperatures from -20°C to +55°C and is powered by durable LR6 batteries with an extended life of up to 350 hours. Its compact dimensions (272 mm height, 92 mm length, 41 mm width) and lightweight 600 g form factor ensure easy portability for technicians and engineers.

Measures AC and DC current up to 1500 A DC with accuracy ±1 % reading plus 3 digits. Voltage measurements up to 1700 V DC with 10 mV resolution and ±1 % accuracy. True RMS ensures accurate measurement independent of signal waveform.

Robust IEC 61010 compliant safety approvals for CAT IV 1000 V and CAT III 1500 V categories. Functions include resistance, phase rotation, harmonics analysis, power measurement, and continuity testing. 48 mm maximum conductor diameter capacity for broad application scope.

Backlit LCD display enhances readability in varied lighting conditions. Long battery life supports extended field use and reduces downtime.

This Clamp Meter is ideal for electricians, industrial maintenance personnel, and HVAC technicians requiring accurate, safe, and versatile electrical testing in the field or workshop. The F405 supports compliance and safety verification tasks in medium power electrical installations and is built for demanding industrial environments.
