Chauvin Arnoux AC/DC Clamp Meter 1500 A DC 1400 V DC CAT IV, True RMS, Model F403 P01120944

Chauvin Arnoux F403 Clamp Meter is a precision AC/DC clamp meter designed for industrial, laboratory, electrical, HVAC, and maintenance applications requiring accurate measurement of current and voltage in medium-power installations.

This clamp meter supports a maximum DC current of 1500 A and DC voltage measurement up to 1400 V. It integrates True RMS technology for enhanced precision across non-linear loads and varying signal waveforms. The unit features a clamping jaw diameter of 48 mm, suitable for conductors up to 34 mm diameter, and provides multiple measurement functions such as AC and DC currents and voltages, resistance, and temperature.

Robust construction with CAT IV 1.5 kV safety category rating ensures safe operation in high-energy installations. The meter operates across an extended temperature range from -60°C to +1000°C, making it suitable for challenging environments. The backlit LCD display ensures clear visibility during measurement tasks even in poorly lit areas, and the meter is powered by standard LR6 batteries with up to 350 hours battery life.

Additional features include automatic AC/DC detection, inrush current measurement, hold, min/max recording functions, relative and differential measurements, and IP54 protection rating for dust and water resistance. The meter complies with IEC 61010 standards, assuring consistent quality and safety.

This Chauvin Arnoux F403 model is ideal for electrical test and measurement professionals working in industrial plants, manufacturing, building maintenance, HVAC, and power distribution systems.

True RMS measurement for accurate readings on complex signals. Maximum DC current measurement of 1500 A and DC voltage up to 1400 V. Clamp jaw opening of 48 mm accommodates conductors up to 34 mm diameter. Wide temperature operating range from -60°C to +1000°C.

Equipped with LCD backlight for easy reading in low light conditions. Battery life up to 350 hours powered by LR6 type batteries. Multiple measured functions including AC/DC current, voltage, resistance, and temperature.

CAT IV 1.5 kV safety rating ensures protection for high-level electrical installations. Compact dimensions: 222 mm height, 78 mm length, and 42 mm width.

Browse more industrial measurement instruments and Clamp Meters like this Chauvin Arnoux model in EnvMart's extensive catalog for precise and reliable electrical testing solutions.
