Microchip Operational Amplifier 1.2 MHz 14-Pin Surface Mount SOIC 16V MCP6H04-E/SL
Specifications
| Country of Origin | Thailand |
|---|---|
| Brand | Microchip |
| Height | 1.25mm |
| Length | 8.65mm |
| Model | MCP6H04-E/SL |
| Width | 3.9mm |
| Mount Type | Surface |
| Series | MCP6H04 |
| Output Current | 65mA |
| Maximum Operating Temperature | 125°C |
| Package Type | SOIC |
| Minimum Operating Temperature | -40°C |
| Number Of Channels | 4 |
| Standards/Approvals | RoHS |
| Pay online using | Or choose to pay later via bank transfer |
| RS Stock No. | 738-7177PBrand: MicrochipManufacturers Part No.: MCP6H04-E/SL |
| Pin Count | 14 |
| Maximum Supply Voltage | 16V |
| Minimum Supply Voltage | 3.5V |
| GBP - Gain Bandwidth Product | 1.2MHz |
| Input Bias Current | 10 pA |
| Vos - Input Offset Voltage | 3.5 mV |
| Slew Rate | 0.8V/μs |
| Input Offset Current | 1 pA |
Key Features
- Features a gain bandwidth product of 1.2 MHz.
- Operates within a supply voltage range of 3.5 to 16 volts.
- Low input bias current of 10 pA ensures high sensitivity.
- Wide operating temperature range from -40°C to 125°C for industrial use.
- Includes four channels with a 14-pin count interface.
- Output current rated at 65 mA for versatile driving capability.
- Input offset voltage of 3.5 mV and input offset current of 1 pA for precision amplification.
- RoHS compliant ensuring environmental safety.
Product Description
Microchip MCP6H04-E/SL is a high-performance operational amplifier featuring a 1.2 MHz gain bandwidth product, designed in a 14-pin Surface Mount SOIC package. This amplifier supports 4 channels, making it suitable for multi-amplifier applications in electronics and semiconductor industries.
It operates over a supply range from 3.5 V to 16 V and works reliably across a wide temperature range of -40°C to 125°C, suitable for industrial, laboratory, and manufacturing environments. The compact form factor (8.65 mm length, 3.9 mm width, 1.25 mm height) allows integration into dense PCB designs.
The device offers low input bias current (10 pA) and input offset current (1 pA), combined with an input offset voltage of just 3.5 mV, ensuring accurate and stable signal amplification. The output current capability is rated at 65 mA, providing robust load driving capacity.
Being RoHS compliant, this operational amplifier meets environmental and safety standards. Manufactured in Thailand, it maintains high quality and reliability for demanding electronic applications.
Gain bandwidth product of 1.2 MHz. Supply voltage range from 3.5 V to 16 V. Low input bias and offset currents optimize performance. Wide operating temperature supports harsh environments. Compact 14-pin SOIC surface mount package.
Output current of 65 mA for versatile applications. Four channel design for multiple signal amplification. RoHS compliant ensuring eco-friendly manufacturing. Reliable manufacture from Thailand.
This operational amplifier is suitable for industrial, laboratory, and electronic circuit design uses where precise amplification and reliability are critical. Explore more Operational Amplifier products and related semiconductor components on EnvMart for efficient electronics development and manufacturing.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The gain bandwidth product of this operational amplifier is 1.2 MHz.
It operates within a supply voltage range of 3.5 V to 16 V.
The output current is rated at 65 mA, allowing for versatile driving capability.
This operational amplifier has a length of 8.65 mm, a width of 3.9 mm, and a height of 1.25 mm.
It features four channels, making it suitable for multi-amplifier applications.
The input bias current is 10 pA, which ensures high sensitivity.
It operates within a wide temperature range from -40°C to 125°C.
The input offset voltage is 3.5 mV, contributing to precision amplification.
It is packaged in a 14-pin Surface Mount SOIC configuration.
Yes, it is RoHS compliant, ensuring it meets environmental safety standards.
The input offset current is 1 pA, which aids in maintaining signal accuracy.
The slew rate is 0.8 V/μs, which is important for signal response time.
