Microchip Operational Amplifier MCP6004-E/SL 1 MHz Gain Bandwidth, 4 Channel, 14-Pin SOIC, 3-6 V
Specifications
| Country of Origin | Thailand |
|---|---|
| Brand | Microchip |
| Height | 1.25mm |
| Length | 8.65mm |
| Model | MCP6004-E/SL |
| Width | 3.9mm |
| Mount Type | Surface |
| Series | MCP6004 |
| Output Current | 23mA |
| Maximum Operating Temperature | 125°C |
| Package Type | SOIC |
| Minimum Operating Temperature | -40°C |
| Number Of Channels | 4 |
| Standards/Approvals | RoHS |
| Pay online using | Or choose to pay later via bank transfer |
| RS Stock No. | 738-6193Brand: MicrochipManufacturers Part No.: MCP6004-E/SLDistrelec Article No.: 304-45-500 |
| Pin Count | 14 |
| Maximum Supply Voltage | 6V |
| Minimum Supply Voltage | 3V |
| GBP - Gain Bandwidth Product | 1MHz |
| Input Bias Current | 19 pA |
| Vos - Input Offset Voltage | 4.5 mV |
| Slew Rate | 0.6V/μs |
| Input Offset Current | 1 pA |
Key Features
- This operational amplifier features a 1 MHz gain bandwidth product suitable for precision applications.
- It supports a supply voltage range from 3 V minimum to 6 V maximum.
- The low input bias current of 19 picoamperes ensures high accuracy signal amplification.
- The device operates over a temperature range from -40°C to 125°C, suitable for industrial environments.
- Its compact dimensions are 8.65 mm length, 3.9 mm width, and 1.25 mm height in a SOIC package.
- It includes four independent amplifier channels with 14-pin configuration.
- The amplifier offers a slew rate of 0.6 V/μs for rapid signal response.
- The input offset voltage is low at 4.5 mV, enhancing measurement precision.
Product Description
Microchip MCP6004-E/SL is an advanced operational amplifier designed for electronic applications requiring precision signal processing. This device features a 1 MHz gain bandwidth product and four independent channels integrated into a compact 14-pin SOIC surface-mount package. Operating at a supply voltage range between 3 V and 6 V, it is suitable for various power-limited systems.
With an input bias current as low as 19 picoamperes and an input offset voltage of 4.5 mV, the MCP6004-E/SL provides excellent signal fidelity and accuracy. Its slew rate of 0.6 V/μs supports applications requiring fast signal transitions, making it versatile for industrial, commercial, and laboratory electronics.
The device is rated for operation across a broad temperature range, from -40°C up to 125°C, ensuring reliable performance in harsh environments. The package size is compact with dimensions of 8.65 mm in length, 3.9 mm width, and 1.25 mm height, optimized for space-constrained PCB designs.
This operational amplifier complies with RoHS standards, reflecting environmental considerations during manufacturing. Originating from Thailand, the MCP6004-E/SL is part of the MCP6004 series renowned for stable operation and durability.
1 MHz gain bandwidth supports precise amplification tasks. Wide supply voltage range of 3 V to 6 V facilitates flexibility in power design. Low input bias current and offset voltage improve signal accuracy. Four independent amplifier channels integrate multiple functions.
Compact SOIC 14-pin packaging suits modern PCB layouts. Robust operating temperature range enables industrial-grade applications. Compliance with RoHS ensures adherence to environmental standards.
This microchip Operational Amplifier is ideal for electronics development, embedded systems, instrumentation, and control applications. Explore more Microchip semiconductor components at EnvMart for your industrial and electronic assembly needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The MCP6004-E/SL has a gain bandwidth product of 1 MHz, making it suitable for precision signal amplification applications.
This model operates within a supply voltage range of 3 V to 6 V, providing flexibility for various power designs.
The maximum operating temperature for this operational amplifier is 125°C, allowing it to function reliably in harsh environments.
This operational amplifier features four independent channels, enabling multiple signal processing functions.
The dimensions of this unit are 8.65 mm in length, 3.9 mm in width, and 1.25 mm in height, designed for compact PCB layouts.
The input bias current for the MCP6004-E/SL is 19 picoamperes, which contributes to its high accuracy in signal amplification.
This operational amplifier has a slew rate of 0.6 V/μs, enabling rapid signal response for various applications.
The input offset voltage of the MCP6004-E/SL is low at 4.5 mV, enhancing measurement precision in signal processing.
It is packaged in a 14-pin SOIC (Small Outline Integrated Circuit) format, suitable for surface mount applications.
Yes, this operational amplifier complies with RoHS standards, reflecting environmental considerations during its manufacturing.
The minimum operating temperature for the MCP6004-E/SL is -40°C, making it suitable for industrial applications.
This operational amplifier can provide an output current of up to 23 mA, supporting a variety of signal processing needs.
