MEAN WELL IP67 5 Output Dimmable Constant Current and Voltage LED Driver 36 V 320.4 W 8.9 A 1 to 10 V PWM Resistance

MEAN WELL HLG-320H-36B is an IP67-rated LED driver with 5 outputs, providing dimmable constant current and voltage operation rated at 36 V, 320.4 W power, and 8.9 A driver current. It is designed for industrial-grade LED lighting applications including street lighting and other commercial illumination systems requiring robust performance both indoors and outdoors.

This LED driver features a universal AC input voltage range and is capable of operating safely in wet and damp environments. It incorporates a built-in 3-in-1 dimming function allowing dimming via 1 to 10 V DC, PWM signals, or variable resistance, providing flexible lighting control options.

The constant voltage output and built-in active power factor correction (PFC) ensure high operational efficiency and stable power delivery to LEDs. Comprehensive protection mechanisms including short circuit, overload, over voltage, and over temperature safeguards contribute to long-term reliability and system safety.

Constructed in an enclosed configuration with screw mount type and wire terminal connections, this driver facilitates secure installation. Its robust IP67 rating confirms protection against dust ingress and water immersion, allowing installation in challenging environments.

MEAN WELL HLG-320H-36B complies with global regulatory standards such as UL8750, EN61347-1, EN61347-2-13, and certifications including cULus and TUV. EMC compliance includes EN55015 and EN55022 standards, suitable for demanding electrical and lighting environments.

Typical industrial applications include LED street lighting, architectural lighting, and commercial LED fixtures requiring reliable and dimmable power sources with high efficiency and environmental resistance.

Provides a universal AC input voltage range and IP67-rated design for indoor and outdoor use. Features 3-in-1 dimming function compatible with 1 to 10 Vdc, PWM signal, or resistance dimming. Equipped with constant voltage output mode and built-in active power factor correction for efficiency.

Includes multiple protection functions such as short circuit, overload, over voltage, and over temperature. Designed for LED lighting and street lighting, suitable for dry, damp, or wet locations. Compliant with international safety and EMC standards including UL, SELV, EN, EAC, CSA, CE, and CB.

Constructed with enclosed configuration and wire terminal type for secure mounting and wiring. Explore our extensive range of LED drivers and power supplies at EnvMart for all your lighting needs.
