ABB System Pro M Compact S200 Miniature Circuit Breaker 1-Pole 8A Type K 230V AC 72V DC 10kA Breaking 2CDS251001R0407 S201-K8

ABB 2CDS251001R0407 S201-K8 System Pro M Compact S200 miniature circuit breaker offers robust electrical protection with 8A current rating and breaking capacity of 10kA at rated voltages of 230V AC and 72V DC. This single-pole device is engineered for commercial and industrial electrical systems to safeguard against overloads and short circuits.

Featuring a thermal electromechanical tripping mechanism with Type K characteristics, it manages high inrush currents commonly found in motor loads or inductive circuits. The screw terminal type ensures reliable and secure electrical connections. The breaker is designed for easy integration on standard DIN rails, simplifying installation in electrical panels and distribution boxes.

ABB S200 series miniature circuit breakers are built complying with IEC/EN 60898-1 and IEC/EN 60947-2 industry standards, ensuring global quality and safety benchmarks. The device has an IP20 and IP40 rating, offering protection from solid foreign objects and limited ingress of water.

The compact design includes dimensions of 69mm height, 69mm depth, and 17.5mm width, providing space-efficient installation in control panels. The lever actuator allows for quick manual resetting after tripping events.

Typical industrial uses include protecting electrical installations in commercial buildings, machinery safety in industrial automation, and providing reliable circuit control in power distribution systems. Its better world claim highlights design for disassembly, underlining sustainability considerations.

Designed with 1-pole configuration for single-phase applications. Type K tripping characteristics support high inrush current loads. Capable of operating at 230V AC and 72V DC voltages. Equipped with thermal electromechanical tripping mechanism for dependable performance.

Facilitates easy installation with DIN rail mounting type. Constructed with screw terminals ensuring secure connections. Complies with IEC/EN 60898-1 and IEC/EN 60947-2 standards. Compact dimensions of 69mm height, 69mm depth, and 17.5mm width.

IP ratings IP20 and IP40 protect against ingress of objects. Lever reset actuator allows simple manual operation.

This ABB miniature circuit breaker is engineered to provide essential safety and control for electrical distribution in industrial, commercial, and certain residential settings. Browse the Electronics & Electricals > Circuit Breakers & Fuse > Miniature Circuit Breaker category for related electrical protection devices at EnvMart.
