MEAN WELL IP67 1 Output LED Driver, 54V, 60.48W, 1.12A Constant Voltage

Free Delivery in India | Lowest Global Shipping Charges

MEAN WELL IP67 1 Output LED Driver, 54V, 60.48W, 1.12A Constant Voltage

Name: MEAN WELL IP67 1 Output LED Driver, 54V, 60.48W, 1.12A Constant Voltage
Brand: MEAN WELL
SKU: 361338
Price: 20.22 USD
Availability: InStock



Category Electronic Components, Power & Connectors Brand MEAN WELL Condition New

Specifications

Country of Origin	China
Brand	MEAN WELL
Model	IP67
IP Rating	IP67
Mount Type	Screw
Series	LPF-60
Configuration	Enclosed
Sub Type	LED Driver
Operating Modes	Constant Voltage
Number of outputs	1
Terminal type	Wire
Maximum Output Power	60.48W
Input Voltage	305, 90, 127, 431V ac
Output Voltage	54V
Power Dissipation	60.48W
Standards/Approvals	SELV, UL, ENEC, BIS, CB, CE, EAC
Pay online using	Or choose to pay later via bank transfer
Primary Type	AC-DC
Driver Current	1.12A

Key Features

Fully encapsulated IP67 waterproof LED driver suitable for dry and damp locations.
Universal AC input with active Power Factor Correction (PFC) for energy efficiency.
Enclosed screw mount type for secure installation.
High efficiency up to 90% with built-in protections against short circuit, overload, over voltage, and over temperature.
Designed to meet global safety and EMC standards including SELV, UL, ENEC, BIS, CB, CE, and EAC.
Operates in constant voltage mode with wire terminal type connectors.
Compliance with harmonic current and electromagnetic compatibility regulations.
Ideal for LED lighting and moving lighting applications in industrial and commercial environments.

Product Description

MEAN WELL LPF-60-54 is a reliable, waterproof IP67 rated LED driver delivering 54 volts constant voltage output with a maximum power of 60.48 watts and a driver current of 1.12 amps. Designed for universal AC input voltages ranging between 90 to 305 volts, this enclosed AC-DC driver features a screw mount type for stable installation and wire terminal connections for ease of wiring.

This LED driver is fully encapsulated for IP67 protection making it suitable for use in wet or damp environments and outdoor lighting fixtures. It incorporates active Power Factor Correction (PFC) to optimize power consumption and reduce harmonic distortion. The plastic casing ensures full isolation of electrical components, enhancing safety and durability.

It complies with multiple international standards such as SELV, UL8750, EN61347 series, BIS, CB, CE, EAC, and meets EMC requirements per EN55015. Protection mechanisms include short circuit, overload, over voltage, and over temperature safeguarding the connected LED load and the driver itself.

These qualities make the MEAN WELL LPF-60-54 LED driver an excellent choice for industrial, commercial, and architectural LED lighting projects where waterproof and robust constant voltage power supplies are required. Its high efficiency, up to 90%, contributes to reduced energy costs and improved system reliability.

Fully encapsulated IP67 waterproof design for harsh environments. Active PFC function ensuring efficient power use. Short circuit, overload, over voltage, and temperature protections. Compliant with a wide range of international safety and EMC standards.

Screw mount and wire terminal for secure, easy installation. Universal AC input for flexible deployment globally. Constant voltage operation ideal for LED lighting applications. High efficiency up to 90% reducing energy consumption.

Plastic isolated case for electrical safety. Single output configuration from LPF-60 series. Explore EnvMart's extensive LED Drivers category to find compatible power supplies and accessories by MEAN WELL and other leading brands.
