TRACOPOWER 40W Single Output DC/DC Converter, 15V DC Output, 2.67A, 9V-18V DC Input, PCB Mount, DIP Package, TEN 40-1213N
Specifications
| Country of Origin | Taiwan |
|---|---|
| Brand | TRACOPOWER |
| Efficiency | 90% |
| Length | 50.8mm |
| Model | TEN 40-1213N |
| Depth | 11mm |
| Mount Type | PCB |
| Series | TEN 40N |
| Maximum Operating Temperature | 85°C |
| Package Type | DIP |
| Minimum Operating Temperature | -40°C |
| MTBF | 328000h |
| Number of outputs | 1 |
| Maximum Output Power | 40W |
| Maximum Input Voltage | 18V dc |
| Minimum Input Voltage | 9V |
| Pay online using | Or choose to pay later via bank transfer |
| Number of Pins | 6 |
| Output Voltage 1 | 15V dc |
| Output Current 1 | 2.67A |
| Isolation Voltage | 1.5kV dc |
Key Features
- Operates with a wide input voltage range from 9V to 18V DC.
- High efficiency of up to 90% ensures low power loss during operation.
- Compact DIP package suitable for space-constrained PCB designs.
- Designed to operate in extreme temperatures from -40°C to 85°C.
- Features 1.5kV DC isolation voltage for enhanced electrical safety.
- Equipped with 6 pins and PCB mount type for easy integration.
- Typical applications include mobile equipment and industrial communication electronics.
- Ensures long MTBF of 328,000 hours for reliability in critical applications.
Product Description
TRACOPOWER TEN 40-1213N is a 40W single output DC/DC converter delivering 15V DC at 2.67A with an input operating voltage range of 9V to 18V DC. Designed in a compact DIP package for PCB mounting, this converter provides a high efficiency of up to 90% and features robust electrical isolation with 1.5kV DC isolation voltage.
It is engineered to operate reliably in harsh industrial environments with temperature tolerance from -40°C to 85°C. The device is suitable for applications in mobile equipment, instrumentation, and distributed power architectures within communication and industrial electronics. Its compact footprint of approximately 50.8mm length and 11mm depth makes it ideal for space-saving designs.
The output voltage can be finely adjusted through an external resistor, allowing customized voltage control. Protection features include short circuit and overvoltage safeguard to ensure device and system integrity. With an MTBF of 328,000 hours, this module proves highly reliable in demanding industrial scenarios.
The TEN 40-1213N DC/DC Converter complies fully with EMC requirements including EN 55022 Class A and FCC Part 15 Level A without the need for additional external components, ensuring electromagnetic compatibility in sensitive equipment.
Operates over an input voltage range of 9V to 18V DC. Delivers regulated 15V DC output with a current capacity of 2.67A. High efficiency operation at up to 90% minimizes energy loss. Compact DIP package type with 6 pins for PCB mounting.
Wide operating temperature range from -40°C to 85°C supports harsh environments. 1.5kV DC isolation voltage enhances safety and system resilience. Output voltage adjustable via external resistor for design flexibility. Short circuit and overvoltage protection safeguards device and circuits.
MTBF of 328,000 hours ensures high reliability. Meets EMC standards EN 55022 Class A and FCC Part 15 Level A.
This TRACOPOWER series TEN 40N converter is an excellent choice for industrial, communication, and mobile power supply applications where compact size, high efficiency, and reliability are critical. EnvMart offers this product for professional use in electronic assemblies and device power management.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model operates with an input voltage range from 9V to 18V DC.
It delivers a regulated output voltage of 15V DC with a current capacity of 2.67A.
The converter has a high efficiency rating of up to 90%, minimizing energy loss during operation.
The dimensions are approximately 50.8mm in length and 11mm in depth.
It is designed to operate in extreme temperatures ranging from -40°C to 85°C.
This model is designed for PCB mounting and comes in a compact DIP package with 6 pins.
It includes short circuit and overvoltage protection to safeguard the device and connected circuits.
The converter features an isolation voltage of 1.5kV DC, enhancing electrical safety.
The MTBF is rated at 328,000 hours, indicating high reliability in critical applications.
It complies with EMC requirements including EN 55022 Class A and FCC Part 15 Level A without the need for additional components.
Yes, the output voltage can be finely adjusted through an external resistor for design flexibility.
It is suitable for applications in mobile equipment, instrumentation, and industrial communication electronics.
