Weidmüller OMNIMATE SL Series Pluggable Terminal Block 10-Contact 5.08 mm Pitch 1 Row 400V 19A 1780260000

Weidmüller 1780260000 OMNIMATE SL Series Pluggable Terminal Block is a high-quality connector designed for wire-to-board connections in electronic and industrial applications. Featuring 10 contacts with a 5.08 mm pitch and a single-row layout, it operates at up to 400V and 19A current to provide reliable electrical performance. This terminal block has a fibreglass liquid crystal polymer housing that ensures resistance to heat and mechanical stress, making it suitable for harsh environments.

The product uses a male connector design with a right-angle orientation optimized for surface mount technology (SMT) boards. It supports wire connection by soldering, making it compatible with wave and reflow soldering processes. The overall compact dimensions of 52.7 mm width, 11.6 mm length, and 12 mm depth facilitate integration into tight PCB layouts. Horizontal closed ends and SMT headers with 3.2 mm pin lengths contribute to its robust mechanical stability.

The OMNIMATE SL series is known for its versatility and secure connection features, including molded male headers available in straight or 90° configurations. Polarising pins prevent mismatched connections, enhancing safety and reliability. This terminal block is manufactured in Germany, reflecting stringent quality control and engineering standards. It supports screw clamp types accommodating wires up to 1.5 mm² and offers tension clamp and push-in screwless technology variants for faster assembly.

This terminal block is ideal for various industrial uses including automation systems, electronic components assembly, and power connectors for PCB applications. Its durable materials and precise dimensions ensure dependable contact and long service life in demanding environments.

The terminal block features a fibreglass liquid crystal polymer housing for durability. Connector gender is male with right angle orientation fitting SMT applications. Suitable for solder wire connection method ensuring stable electrical contacts.

The unit measures 52.7 mm width, 11.6 mm length, and 12 mm depth for compact PCB integration. It supports horizontal closed ends and SMT headers with 3.2 mm pin length for wave or reflow soldering. Moluded male headers come in straight or 90° PCB pin options preventing mismatches.

The design includes polarising pins for secure and correct connections. Manufactured in Germany with the OMNIMATE SL series quality standards. It complies with industrial electrical requirements but has no specific standards or approvals listed.

Ideal for electronic, industrial automation, and power connecting applications on PCBs. Explore the comprehensive range of Weidmüller Pluggable Terminal Blocks at EnvMart for your technical and industrial connector needs.
