Weidmüller OMNIMATE SL Series Pluggable Terminal Block 9-Contact 5.08 mm Pitch, 1 Row 1780020000

Weidmüller 1780020000 OMNIMATE SL Series Pluggable Terminal Block is a high-quality connector designed for robust and reliable wire-to-board electrical applications. It features a 9-contact configuration with a 5.08 mm pitch and a single row, making it ideal for space-conscious industrial and electronic circuit designs.

The terminal block housing is made from glass filled liquid crystal polymer, providing excellent resistance to high temperatures and mechanical stress. Rated for a current capacity of 19 A and voltage rating of 400 V, it ensures dependable electrical performance under demanding conditions.

This connector is engineered with a male connector gender and right angle orientation, allowing efficient PCB design layouts. The solder wire connection method supports wave or reflow soldering, with 3.2 mm pin length compatible with surface mount technology.

The product complies with international safety standards IEC 60664-1, IEC 61984, RoHS directives, and UL 1059 certification, ensuring safe and environmentally compliant operation. Its compact design - width of 45.72 mm and depth of 12 mm - fits standard PCB configurations with a precision pitch of 5.08 mm.

Polarising pins are integrated to prevent incorrect mating and ensure secure connections, further enhancing system reliability. These features make it suitable for industrial automation, control panels, power supply systems, and electronic manufacturing environments.

Manufactured in Germany, this pluggable terminal block reflects rigorous quality and manufacturing standards. It is part of the OMNIMATE SL series, renowned for durable and precise connectors.

Features a durable glass filled liquid crystal polymer housing for enhanced heat resistance. Supports a rated current of 19 A and a voltage rating of 400 V for reliable power transmission. Designed for solder wire connection with a male connector gender configuration.

Compliant with IEC 60664-1, IEC 61984, RoHS, and UL 1059 safety standards. Compact dimensions offer a width of 45.72 mm, depth of 12 mm, and single row design for PCB mounting. Right angle orientation facilitates flexible PCB layout configurations.

Suitable for wave or reflow soldering processes with 3.2 mm pin length and high temperature body material. Polarising pins prevent connector mismatches, enhancing installation safety. Originates from Germany, ensuring high quality manufacturing standards.

Explore the OMNIMATE SL series and other Weidmüller connectors on EnvMart for precision electrical interconnect solutions suitable for diverse industrial and manufacturing needs.
