Microchip 10-Bit Digital-to-Analogue Converter SPI Interface Through Hole PDIP 8-Pin MCP4911-E/P
Specifications
| Country of Origin | Thailand |
|---|---|
| Resolution | 10 bit |
| Brand | Microchip |
| Height | 5.3mm |
| Length | 10.1mm |
| Model | MCP4911-E/P |
| Width | 7.1mm |
| Mount Type | Through Hole |
| Settling Time | 4.5μs |
| Output type | Analogue Voltage |
| Maximum Operating Temperature | 125°C |
| Package Type | PDIP |
| Minimum Operating Temperature | -40°C |
| Number Of Channels | 1 |
| Interface Type | SPI |
| Architecture | Resistor String |
| Pay online using | Or choose to pay later via bank transfer |
| RS Stock No. | 726-3882PBrand: MicrochipManufacturers Part No.: MCP4911-E/P |
| Pin Count | 8 |
| Maximum Supply Voltage | 5.5V |
| Minimum Supply Voltage | 2.7V |
Key Features
- Resistor String architecture provides reliable conversion performance.
- Operates with a single channel output for simplicity.
- Supports voltage reference from external sources for flexible voltage control.
- Operates within a supply voltage range of 2.7V to 5.5V.
- Compact dimensions of 10.1mm length, 7.1mm width, and 5.3mm height for space-sensitive designs.
- Fast settling time of 4.5 microseconds ensuring quick signal stabilization.
- Wide operating temperature range from -40°C to 125°C for industrial applicability.
- 8-pin PDIP package enables easy insertion in through-hole PCB layouts.
Product Description
Microchip MCP4911-E/P is a precision 10-bit Digital-to-Analogue Converter (DAC) designed for applications requiring reliable analogue output signals. Featuring a resistor string architecture, this single-channel device converts digital input signals to precise analogue voltages through an SPI interface. Packaged in an 8-pin PDIP suitable for through-hole mounting, the device measures 10.1mm in length, 7.1mm in width, and 5.3mm in height, making it ideal for compact PCB designs.
This DAC operates over a wide supply voltage range from 2.7V to 5.5V, supporting external voltage references for increased flexibility in various circuit environments. It offers a fast settling time of 4.5 microseconds, delivering prompt analogue output stabilization after digital input changes. The broad operating temperature range (-40°C to 125°C) ensures robustness for industrial, laboratory, and embedded system applications.
The MCP4911-E/P outputs analogue voltage signals suitable for control systems, signal processing, and measurement instrumentation. It complies with relevant industrial and semiconductor standards but does not carry specific certifications.
Resistor string architecture for accuracy and stability. Single channel output with SPI interface compatibility. Works with an external voltage reference to optimize output range. Compact 8-pin PDIP package for through-hole PCB assembly.
Wide operating temperature range accommodating harsh environments. Fast response with 4.5µs settling time improving dynamic performance. Supply voltage range from 2.7V to 5.5V suits various embedded systems. Manufactured in Thailand adhering to quality manufacturing processes.
Analogue voltage output for versatile electronic applications. Ideal for industrial, laboratory and embedded applications requiring precision DAC.
This product is part of the comprehensive range of Digital to Analogue Converters available at EnvMart, catering to semiconductor and electronic component needs across multiple industries.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The MCP4911-E/P has a resolution of 10 bits, allowing for precise analogue voltage output from digital input signals.
This model operates within a supply voltage range of 2.7V to 5.5V, making it suitable for various embedded systems.
The settling time for this unit is 4.5 microseconds, ensuring quick stabilization of the analogue output after digital input changes.
It provides an analogue voltage output, which is suitable for control systems, signal processing, and measurement instrumentation.
The MCP4911-E/P comes in an 8-pin PDIP package, designed for through-hole mounting on PCBs.
This DAC operates over a wide temperature range from -40°C to 125°C, making it suitable for industrial applications.
It utilizes an SPI interface for communication, allowing for easy integration into various electronic systems.
This model features a resistor string architecture, which provides reliable conversion performance.
Yes, the MCP4911-E/P supports voltage references from external sources for flexible voltage control.
The dimensions of this unit are 10.1mm in length, 7.1mm in width, and 5.3mm in height, making it compact for space-sensitive designs.
This digital-to-analogue converter has a single channel output, simplifying its use in various applications.
This product is manufactured in Thailand, adhering to quality manufacturing processes.
