Microchip 10 Bit Digital-to-Analogue Converter DAC with SPI Interface, 8-Pin PDIP MCP4911-E/P
Specifications
| Country of Origin | Thailand |
|---|---|
| Resolution | 10 bit |
| Brand | Microchip |
| Height | 5.3mm |
| Length | 10.1mm |
| Model | MCP4911-E/P |
| Width | 7.1mm |
| Mount Type | Through Hole |
| Settling Time | 4.5μs |
| Output type | Analogue Voltage |
| Maximum Operating Temperature | 125°C |
| Package Type | PDIP |
| Minimum Operating Temperature | -40°C |
| Number Of Channels | 1 |
| Interface Type | SPI |
| Architecture | Resistor String |
| Pay online using | Or choose to pay later via bank transfer |
| RS Stock No. | 726-3882Brand: MicrochipManufacturers Part No.: MCP4911-E/P |
| Pin Count | 8 |
| Maximum Supply Voltage | 5.5V |
| Minimum Supply Voltage | 2.7V |
Key Features
- Resistor string architecture for stable output performance.
- Single channel DAC with 10 bit resolution.
- Supports SPI interface protocol for digital communication.
- Compatible with supply voltages ranging from 2.7V to 5.5V.
- Operating temperature range from -40°C to 125°C.
- Compact PDIP 8-pin through-hole mount package with dimensions 10.1 mm length, 7.1 mm width, and 5.3 mm height.
- External voltage reference supported for flexible design options.
- Settling time of 4.5 μs for fast signal response.
Product Description
Microchip MCP4911-E/P is a quality 10 bit Digital-to-Analogue Converter (DAC) featuring a resistor string architecture to provide accurate analogue voltage output. This device is housed in a convenient 8-pin PDIP package designed for through-hole mounting, measuring 10.1 mm in length, 7.1 mm in width, and 5.3 mm in height.
It supports a serial SPI interface for easy integration with digital systems. The DAC operates with supply voltages ranging from 2.7V to 5.5V, suitable for a wide array of electronic applications. The device operates reliably across a broad temperature range from -40°C to 125°C, making it ideal for industrial environments.
The MCP4911-E/P supports external voltage reference input, providing design flexibility for different precision requirements. With a fast settling time of 4.5 microseconds, this DAC is well suited for applications requiring rapid signal conversions.
This product finds uses in industrial control systems, laboratory instrumentation, automotive electronics, and embedded systems requiring precise analogue output voltages. Resistor string architecture ensures stable output performance.
10 bit resolution provides high accuracy digital-to-analogue conversion. Single channel simplifies integration in control circuits. Through-hole PDIP mounting facilitates easy prototyping and repair. Wide operating temperature range supports diverse industrial applications.
Fast settling time enhances responsiveness in control loops. External voltage reference expands design possibilities. Compact form factor saves PCB space. Set contains: 1 Pc Microchip MCP4911-E/P Digital-to-Analogue Converter.
Explore more Digital to Analogue Converters in the Electronics & Electricals category at EnvMart for your industrial and commercial needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The MCP4911-E/P Digital-to-Analogue Converter has a resolution of 10 bits, allowing for precise analogue voltage output.
This model operates reliably within a temperature range of -40°C to 125°C, making it suitable for industrial applications.
It supports supply voltages ranging from 2.7V to 5.5V, accommodating various electronic applications.
The settling time for this DAC is 4.5 microseconds, which enables fast signal response in applications.
The MCP4911-E/P uses a serial SPI interface for digital communication, facilitating easy integration with digital systems.
This model has dimensions of 10.1 mm in length, 7.1 mm in width, and 5.3 mm in height, housed in an 8-pin PDIP package.
The MCP4911-E/P is a single-channel DAC, simplifying integration into control circuits.
It features a resistor string architecture, which ensures stable output performance for accurate analogue voltage conversion.
Yes, the MCP4911-E/P supports an external voltage reference input, providing flexibility for different design requirements.
This model is designed for through-hole mounting, making it convenient for prototyping and repair.
The MCP4911-E/P is manufactured in Thailand, as indicated by its country of origin.
The output type of this DAC is an analogue voltage, suitable for various electronic applications requiring precise voltage levels.
