MEAN WELL IP67 Rated 1 Output LED Driver, 36V, 100.8W, 2.8A Constant Voltage

Free Delivery in India | Lowest Global Shipping Charges

MEAN WELL IP67 Rated 1 Output LED Driver, 36V, 100.8W, 2.8A Constant Voltage

Name: MEAN WELL IP67 Rated 1 Output LED Driver, 36V, 100.8W, 2.8A Constant Voltage
Brand: MEAN WELL
SKU: 359424
Price: 20.22 USD
Availability: InStock



Category Electronic Components, Power & Connectors Brand MEAN WELL Condition New

Specifications

Country of Origin	India
Brand	MEAN WELL
Model	IP67
IP Rating	IP67
Mount Type	Panel
Series	LPV-100
Configuration	Encapsulated
Sub Type	LED Driver
Operating Modes	Constant Voltage
Number of outputs	1
Terminal type	Wire
Maximum Output Power	100.8W
Input Voltage	264, 90, 127, 370V ac
Output Voltage	36V
Power Dissipation	100.8W
Standards/Approvals	CE, EN, TUV
Pay online using	Or choose to pay later via bank transfer
Primary Type	AC-DC
Driver Current	2.8A

Key Features

IP67 rated for waterproof and dustproof protection suitable for outdoor and indoor use.
High efficiency and long lifespan ensuring reliable LED operation.
Supports wide input voltage range from 90V to 370V AC.
Includes built-in protections against short circuit, over-current, and over-voltage.
Designed for panel mounting with encapsulated AC-DC configuration.
Complies with CE, EN, and TUV standards for safety and EMC.
300mm un-terminated input and output leads for flexible installation.
Withstands 300Vac surge input for 5 seconds enhancing robustness.

Product Description

MEAN WELL LPV-100-36 IP67 rated LED Driver is a reliable and efficient 1 output LED driver designed for industrial and commercial LED lighting systems requiring a constant voltage power supply at 36 volts and 2.8 amperes output current. This 100.8 watt power supply unit features waterproof encapsulation suitable for indoor or outdoor applications, including moving signs and LED panels.

The driver operates over a wide input voltage range including 90V, 127V, 264V, and up to 370V AC, ensuring compatibility with various power systems. It is designed for panel mounting with 300mm un-terminated wire leads for both input and output, allowing flexible installations.

Key industrial protections include short circuit, over-current, and over-voltage safeguards, along with compliance to electromagnetic compatibility standards EN 55022 Class B and harmonic current compliance EN 61000-3-2 and -3. The product undergoes 100% full load burn-in testing for quality assurance.

This LED driver delivers stable constant voltage output with an encapsulated AC-DC power configuration, making it suitable for LED lighting components used in industrial plants, manufacturing environments, commercial installations, and HVAC lighting solutions. The IP67 ingress protection rating guarantees reliable performance in challenging environmental conditions requiring waterproof and dustproof capabilities.

MEAN WELL's LPV-100 series products are known for high efficiency, long life, and durability. The design allows withstanding surge voltages up to 300Vac for 5 seconds, enhancing system robustness. For detailed design and integration, technical documents including RoHS certificate and statement of conformity are available.

IP67 rated waterproof and dustproof LED driver. Constant voltage output at 36V, 2.8A with 100.8W power. Wide AC input range from 90V to 370V. Robust protections against electrical faults. Panel mount with encapsulated AC-DC configuration.

Compliant with CE, EN, and TUV safety standards. Ideal for industrial, commercial, and outdoor LED lighting applications. Includes 300mm lead wires for flexible installation. Explore MEAN WELL LED drivers and related LED lighting components at EnvMart for professional and industrial use.
