TE Connectivity Slide Rotary Coded DIP Switch Through Hole 1825360-3

TE Connectivity 1825360-3 Slide Rotary Coded DIP Switch is a through hole mounting switch designed for reliable electronic circuit control. It features a slide actuator type suitable for industrial and commercial applications where precise rotary switch actuation is needed.

The device is constructed with gold flash plated contacts providing excellent conductivity and resistance to corrosion. The black PPS housing ensures mechanical stability and durability under demanding conditions. The switch size of 7.5 x 3.5 mm with a 2.54 mm centerline pitch makes it compatible with standard PCB layouts.

This DIP switch supports high pressure wiping contact technology which permits aqueous or solvent cleaning without the need for tape sealing, enabling easy maintenance and cleaning. It is also capable of withstanding vapor phase reflow and wave soldering assembly processes commonly used in industrial manufacturing environments.

With a low contact resistance of 50 milliohms, the switch ensures efficient and stable electrical connections. The series includes ADE and ADF variants; the ADE with extended slide actuators and ADF with flush slide actuators. The 1825360-3 model specifically features a slide actuator facilitating smooth and dependable switching.

This component is auto insertable, increasing production efficiency by easing automated assembly in manufacturing lines. It is ideal for applications in electronics, automation systems, instrumentation, and industrial control equipment.

Through hole mount type ensures secure PCB installation. Slide actuator type provides precise switch operation. Dimensions are 7.5 x 3.5 mm with a 2.54 mm centerline pitch. Gold flash plated contacts enhance conductivity and corrosion resistance.

Black PPS housing provides durability and mechanical stability. High pressure wiping contact allows aqueous or solvent cleaning without tape seal. Compatible with vapor phase reflow and wave soldering processes. Contact resistance is 50 milliohms for efficient electrical performance.

Auto insertable design facilitates efficient manufacturing and assembly.

This switch suits industrial automation, electronic manufacturing, and control system applications. For more TE Connectivity products, browse the Rotary Coded DIP Switch category on EnvMart.
