Murata Power Solutions 3 mH Leaded Inductor Radial Mount 1.9 A Idc 97 mΩ Rdc 21mm Diameter 24mm Height Model 51305C
Specifications
| Country of Origin | China |
|---|---|
| Diameter | 21mm |
| Brand | Murata Power Solutions |
| Height | 24mm |
| Length | 18mm |
| Model | 51305C |
| Depth | 10mm |
| Packaging | Tray |
| Mount Type | Radial |
| Series | 5100 |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -40°C |
| Inductance | 3mH |
| Standards/Approvals | RoHS |
| Pay online using | Or choose to pay later via bank transfer |
| RS Stock No. | 715-7106PBrand: Murata Power SolutionsManufacturers Part No.: 51305C |
| Maximum DC Current | 1.9A |
| Maximum DC Resistance | 97mΩ |
| Termination Style | Solder |
| Lead Pitch | 12.7mm |
| Lead Diameter | 1mm |
Key Features
- Inductance of 3 mH with maximum DC current rating of 1.9 A.
- Maximum DC resistance of 97 mΩ ensures low power loss.
- Radial mount type suitable for through-hole PCB assembly.
- Compact dimensions with 21 mm diameter and 24 mm height.
- Operating temperature range from -40°C to 125°C for wide application environments.
- Leaded inductor packaged in trays for ease of handling and assembly.
- Lead pitch is 12.7 mm with 1 mm lead diameter for secure soldering.
- Termination style is solder for reliable electrical connection.
Product Description
Murata Power Solutions 51305C Leaded Inductor is a 3 mH radial mount device providing a maximum DC current of 1.9 A and a maximum DC resistance of 97 mΩ. Its compact size with a diameter of 21 mm, height of 24 mm, length of 18 mm, and depth of 10 mm makes it suitable for a wide range of industrial applications.
Built with UL 94V-0 packaging materials and RoHS compliant, this inductor ensures safety, quality, and environmental friendliness. It is specifically engineered to attenuate up to 100MHz common mode noise, making it ideal for high current switching power supplies, telecom equipment, and other electronic devices requiring line filtering solutions.
The product features radial mounting for through-hole PCBs, lead pitch of 12.7 mm, and 1mm lead diameter to ensure secure and reliable solder connections. Its operating temperature range extends from -40°C to 125°C, supporting diverse environmental conditions.
This 5100 Series common mode choke guarantees a minimal creepage and clearance distance of 3.0 mm between windings, enhancing electrical safety and performance. Inductance of 3 mH with maximum DC current rating of 1.9 A.
Maximum DC resistance of 97 mΩ ensures low power loss. Radial mount and solder termination style for reliable installation. Compact dimensions: 21 mm diameter, 24 mm height, 18 mm length, 10 mm depth. Operating temperature range from -40°C to 125°C.
Packaged in trays for handling convenience. Complies with RoHS environmental standards. Series 5100 with 3.0 mm creepage and clearance between windings.
Murata Power Solutions 51305C is manufactured in China and is suited for use in industrial, telecommunications, power supply, and electronics manufacturing sectors. It supports robust common mode noise attenuation, making it a crucial component for improving electromagnetic compatibility in devices.
Explore more high-quality inductors and related electronic components from Murata Power Solutions on EnvMart for precise and reliable electromagnetic solutions.
Explore more products in our Leaded Inductors category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The inductance of this model is 3 mH.
The maximum DC current rating for this inductor is 1.9 A.
The maximum DC resistance is 97 mΩ, ensuring low power loss.
This model has a diameter of 21 mm, a height of 24 mm, a length of 18 mm, and a depth of 10 mm.
The operating temperature range is from -40°C to 125°C.
It features a radial mount type suitable for through-hole PCB assembly.
The lead pitch is 12.7 mm and the lead diameter is 1 mm.
The termination style is solder, providing a reliable electrical connection.
This model complies with RoHS environmental standards.
It is packaged in trays for ease of handling and assembly.
This inductor is suitable for high current switching power supplies, telecom equipment, and other electronic devices requiring line filtering solutions.
This inductor is manufactured in China.
