Murata Power Solutions 10 mH Leaded Inductor Radial Mount, Max SRF 200 kHz, 600 mA Idc, 2294 mΩ Rdc, 1400 Series 1410606C
Specifications
| Country of Origin | China |
|---|---|
| Diameter | 24.4mm |
| Brand | Murata Power Solutions |
| Operating Temperature | -40 → +85°C |
| Height | 23.3mm |
| Length | 32.4mm |
| Model | 1410606C |
| Depth | 31.3mm |
| Mount Type | Radial |
| Series | 1400 |
| Maximum Operating Temperature | 85°C |
| Minimum Operating Temperature | -40°C |
| Inductance | 10mH |
| Standards/Approvals | RoHS |
| Pay online using | Or choose to pay later via bank transfer |
| RS Stock No. | 715-6850PBrand: Murata Power SolutionsManufacturers Part No.: 1410606C |
| Maximum DC Current | 600mA |
| Maximum DC Resistance | 2294mΩ |
| Inductance Tolerance | ±10% |
| Termination Style | Solder |
| Maximum Self Resonant Frequency | 200kHz |
| Minimum Quality Factor | 48 |
| Lead Pitch | 28.5mm |
| Lead Diameter | 0.54mm |
Key Features
- Constructed with high saturation flux density material for reliable high current performance.
- Maximum operating temperature of 85°C and minimum operating temperature of -40°C for durable use.
- Features a maximum DC current rating of 600 mA and maximum DC resistance of 2294 mΩ.
- Compact radial mount form factor with lead diameter of 0.54 mm and lead pitch of 28.5 mm.
- Maintains inductance tolerance of ±10% and minimum quality factor of 48 for stable electrical characteristics.
- Terminated with easy-strip pre-tinned enamelled copper leads for soldering convenience.
- Maximum self-resonant frequency is 200 kHz, suitable for switching regulators, filters and suppression circuits.
- Diameter measures 24.4 mm, with length 32.4 mm, height 23.3 mm, and depth 31.3 mm.
Product Description
Murata Power Solutions 1410606C is a 10 mH leaded inductor from the 1400 series, optimized for high current applications such as switching regulators, filters, and suppression circuits in industrial and electronic power line settings. It offers a robust radial mount design enabling mounting on printed circuit boards or chassis using a non-magnetic fastener via its central fixing hole.
The inductor is constructed from high saturation flux density material, which supports high current operation up to 600 mA DC current while maintaining a maximum DC resistance of 2294 mΩ. It operates reliably within a temperature range from -40°C to +85°C, suitable for demanding environments.
This radial inductor features a lead diameter of 0.54 mm and a lead pitch of 28.5 mm, with overall dimensions measuring 24.4 mm in diameter, 32.4 mm length, 23.3 mm height, and 31.3 mm depth. It is terminated with easy-strip, pre-tinned enamelled copper leads to facilitate soldering processes.
Electrical performance is stable with a ±10% inductance tolerance and a minimum quality factor of 48, and the inductor achieves a maximum self-resonant frequency of 200 kHz. The component complies with RoHS environmental directives, ensuring safe and sustainable use in modern electronic assemblies.
This product is primarily sourced from China and arrives as part of the 1400 series offering by Murata Power Solutions. It is suitable for use in industrial electronics, manufacturing equipment, power supply units, and HVAC systems where efficient energy filtering and electromagnetic interference suppression are required.
Set contains one high current leaded inductor featuring radial mounting and corrosion-resistant conductor finish. The part number 1410606C uniquely identifies this model, ensuring compatibility and ease of replacement in electronic assemblies.
Explore the Murata Power Solutions category on EnvMart for additional high-performing inductors and other passive electronic components tailored for power and signal conditioning in advanced applications.
Explore more products in our Leaded Inductors category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum DC current rating for this model is 600 mA.
This inductor has an inductance value of 10 mH.
The inductor has a diameter of 24.4 mm, a length of 32.4 mm, a height of 23.3 mm, and a depth of 31.3 mm.
The maximum self-resonant frequency is 200 kHz.
It operates reliably within a temperature range of -40°C to +85°C.
The maximum DC resistance is 2294 mΩ.
This model features a solder termination style with easy-strip, pre-tinned enamelled copper leads.
The lead diameter is 0.54 mm, and the lead pitch is 28.5 mm.
The minimum quality factor for this inductor is 48.
Yes, it complies with RoHS environmental directives.
It is optimized for high current applications such as switching regulators, filters, and suppression circuits.
This inductor is part of the 1400 series from Murata Power Solutions.
