Phoenix Contact Industrial Surge Protector 50 kA, 240 V AC, DIN Rail Mount 2800190
Specifications
| Country of Origin | Germany |
|---|---|
| Brand | Phoenix Contact |
| Length | 47mm |
| Model | 2800190 |
| Depth | 67.3mm |
| IP Rating | IP20 |
| Width | 17.7mm |
| Mount Type | DIN Rail |
| Series | VAL-MS-T1/T2 335/12.5 ST |
| Maximum Operating Temperature | 80°C |
| Minimum Operating Temperature | -40°C |
| Standards/Approvals | IEC 61643-11 |
| Pay online using | Or choose to pay later via bank transfer |
| RS Stock No. | 712-5282Brand: Phoenix ContactManufacturers Part No.: 2800190 |
| Maximum Surge Current | 50kA |
| Voltage Protection Rating | 240V ac |
| Impulse Discharge Current | 12.5kA |
Key Features
- The surge protector is designed for DIN Rail mounting with a compact length of 47 mm, depth of 67.3 mm, and width of 17.7 mm.
- It features an impulse discharge current rating of 12.5 kA for effective surge absorption.
- The product adheres to IEC 61643-11 standards and offers an IP20 protection rating suitable for industrial environments.
- Operating temperature range spans from -40°C minimum to a maximum of 80°C, ensuring durability under varied conditions.
- It incorporates thermal disconnect for each individual plug and floating remote indication contact for monitoring.
- The device is built with mechanical coding on all slots and has a latching mechanism providing high tolerance to voltage fluctuations and vibrations.
- Typical applications include protection for commercial warehouses, industrial factories, and critical infrastructure equipment.
- This varistor-based plug-in lightning and surge protector enhances network and equipment safety against unexpected surges and disturbances.
Product Description
Phoenix Contact 2800190 Surge Protector is a reliable industrial-grade varistor-based device designed to safeguard electrical equipment from high-energy transient surges and overvoltage events. Rated for 50 kA maximum surge current and 240 V AC voltage protection, this DIN Rail mountable protector ensures robust defense for critical automation and electrical systems.
The compact protector measures 47 mm in length, 67.3 mm in depth, and 17.7 mm in width, making it suitable for space-constrained electrical panels. It complies with IEC 61643-11 standards, verifying its quality and safety compliance globally.
Engineered for industrial applications, it supports a broad operating temperature range from -40°C to 80°C and carries an IP20 ingress protection rating, ensuring operational reliability in commercial and industrial environments. The unit integrates a thermal disconnect mechanism per plug to isolate failed surge elements and a floating remote indication contact for remote status monitoring.
This surge protector features mechanical coding on all slots to prevent incorrect installation and a robust latching system that provides surge tolerance against high lightning current loads and vibrations, classified under voltage protection classes 3 and 4.
It is ideal for use in commercial warehouses, industrial factories, and other facilities requiring effective protection of sensitive electrical infrastructure from voltage spikes and transient surges, minimizing downtime and equipment damage.
The surge protector protects networks and equipment against unexpected electrical surges. Designed for simplicity, plugs can be verified using CHECKMASTER testing equipment. Mechanical coding of slots prevents faulty connections ensuring secure installation.
Thermal disconnect protects each plug individually against overcurrent damage. Floating remote indication contact enables easy status monitoring from a distance. Compact DIN Rail mount design fits standard industrial electrical panels efficiently.
Meets IEC 61643-11 surge protection standards. IP20 rated for secure indoor industrial usage.
Phoenix Contact surge protectors combine industrial-grade performance with safety features essential for protecting critical infrastructure. Browse the full range of surge protection solutions suitable for industrial, manufacturing, and commercial electrical networks on EnvMart.
Explore more products in our Surge Protection Devices category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The surge protector has a maximum surge current rating of 50 kA, providing robust protection against high-energy transient surges.
It offers a voltage protection rating of 240 V AC, making it suitable for various industrial applications.
This model measures 47 mm in length, 67.3 mm in depth, and 17.7 mm in width, allowing it to fit into standard DIN Rail mounts.
The operating temperature range spans from -40°C to a maximum of 80°C, ensuring functionality in extreme conditions.
It complies with IEC 61643-11 standards, ensuring its quality and safety for surge protection applications.
Yes, it incorporates a thermal disconnect mechanism for each plug to isolate failed surge elements, enhancing safety during operation.
It is designed for DIN Rail mounting, making installation straightforward in electrical panels.
The unit has an IP20 protection rating, suitable for indoor industrial environments.
The impulse discharge current rating is 12.5 kA, which aids in effective surge absorption.
It features mechanical coding on all slots to prevent incorrect installation and a robust latching mechanism for secure mounting.
Typical applications include protection for commercial warehouses, industrial factories, and critical infrastructure equipment from voltage spikes.
The surge protector is manufactured in Germany, ensuring adherence to high production standards.
