Microchip Digital to Analogue Converter 12 Bit, 2-Channel, SPI Microwire Interface, 8-Pin PDIP MCP4822-E/P

Microchip MCP4822-E/P is a high-performance 12-bit digital-to-analogue converter (DAC) featuring two independent output channels. It uses resistor string architecture to deliver accurate analogue voltage outputs through SPI and Microwire interface communication protocols. The device is housed in an 8-pin PDIP package enabling easy insertion into through-hole PCB designs.

This DAC operates reliably within a supply voltage range of 5 to 5.5 volts and can function across a wide temperature range from -40°C up to 125°C, making it suitable for industrial and automotive electronics applications.

With a fast settling time of 4.5 µs, the MCP4822 enables quick response to input signal changes, enhancing precision control in laboratory instrumentation, HVAC systems, process automation, and industrial manufacturing equipment.

The compact size of 10.1 mm in length, 7.1 mm in width, and 5.3 mm in height supports designs where PCB space optimization is critical. Its analogue voltage output type is standard for signal conditioning and control feedback loops.

Key features include dual channel operation, SPI and Microwire interface compatibility, and robust operating temperature and voltage specifications. These properties make the MCP4822-E/P DAC a versatile component in electronic instrumentation and embedded control systems.

The DAC offers 12-bit resolution for high-accuracy signal conversion. Equipped with 2 output channels for versatile applications. Operates with a supply voltage between 5 V and 5.5 V. Features fast settling time of 4.5 microseconds for responsive output.

Suitable for through-hole mounting with an 8-pin PDIP form factor. Interface compatibility includes SPI and Microwire protocols. Compact dimensions of 10.1 mm length, 7.1 mm width, and 5.3 mm height. Operational temperature range from -40°C to 125°C for reliability in various environments.

Outputs analogue voltage signals suitable for industrial and laboratory control systems.

Explore a wide range of semiconductor devices and Digital to Analogue Converters in the Electronics & Electricals category on EnvMart for industrial, laboratory, and embedded system applications.
