Microchip Digital to Analogue Converter DAC 12 bit Serial-I2C Interface 6-Pin SOT-23 Package MCP4725A0T-E/CH
Specifications
| Country of Origin | India |
|---|---|
| Resolution | 12 bit |
| Brand | Microchip |
| Height | 1.4mm |
| Length | 3.1mm |
| Model | MCP4725A0T-E/CH |
| Width | 1.8mm |
| Mount Type | Surface |
| Settling Time | 6μs |
| Output type | Analogue Voltage |
| Maximum Operating Temperature | 125°C |
| Package Type | SOT-23 |
| Minimum Operating Temperature | -40°C |
| Number Of Channels | 1 |
| Interface Type | Serial-I2C |
| Architecture | Resistor String |
| Pin Count | 6 |
| Maximum Supply Voltage | 5.5V |
| Minimum Supply Voltage | 3.3V |
| Microchip DAC 12 bit- Serial-I2C, 6-Pin SOT-23Brand | Microchip |
Key Features
- Operates at a minimum supply voltage of 3.3 V and maximum of 5.5 V.
- Utilizes resistor string architecture for accurate conversion.
- Supports single channel analogue output voltage.
- Provides fast settling time of 6 microseconds.
- Designed for surface mount with small package dimensions of 3.1 mm length, 1.8 mm width, and 1.4 mm height.
- Operates reliably across extended temperature range from -40°C to 125°C.
- Compatible with external voltage reference to enhance precision.
- Ideal for industrial, laboratory, and electronics design applications requiring precise DAC performance.
Product Description
Microchip MCP4725A0T-E/CH is a 12 bit digital to analogue converter that employs a resistor string architecture and interfaces via Serial-I2C. It comes in a compact 6-pin SOT-23 surface mount package with dimensions of 3.1 x 1.8 x 1.4 mm.
This DAC supports a single analogue output channel, operating over a voltage supply range from 3.3 V to 5.5 V, and provides a fast settling time of 6 microseconds. It is designed to perform efficiently over a wide temperature range from -40°C to 125°C, ensuring reliability in diverse environments.
The device uses an external voltage reference to achieve precise analogue output voltage, making it suitable for applications in industrial instrumentation, laboratory equipment, electronic design and prototyping, and embedded systems where accurate digital to analogue conversion is critical.
The small footprint and surface mount design allow integration into compact PCB layouts and space-constrained applications. It complies with standard quality expectations, although no specific automotive or industry certifications are indicated.
Operates between 3.3 V and 5.5 V supply voltage. 12 bit resolution ensures fine control of output voltage. Resistor string architecture for stability and accuracy. Single channel output ideal for precise control applications.
Extended operating temperature range from -40°C to 125°C. Compact SOT-23 6-pin package dimensioned 3.1 x 1.8 x 1.4 mm. 6 microseconds settling time for rapid signal stabilization. Surface mount technology compatible.
Microchip DAC series devices like MCP4725A0T-E/CH support diverse electronic applications across fields such as industrial control systems, embedded instrumentation, laboratory converters, and consumer electronics requiring reliable digital to analogue signal conversion.
Explore more Digital to Analogue Converters and semiconductor components at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model operates with a supply voltage range from 3.3 V to 5.5 V.
It features a resolution of 12 bits, allowing for fine control of the output voltage.
It utilizes a Serial-I2C interface for communication.
The settling time for this model is 6 microseconds, enabling rapid signal stabilization.
The package dimensions are 3.1 mm in length, 1.8 mm in width, and 1.4 mm in height.
It operates reliably across an extended temperature range from -40°C to 125°C.
This device supports a single analogue output channel.
It employs a resistor string architecture for accurate digital to analogue conversion.
Yes, it is compatible with an external voltage reference to enhance precision.
It is suitable for industrial instrumentation, laboratory equipment, electronic design, and embedded systems requiring precise DAC performance.
This model has a pin count of 6, designed for surface mount technology.
The country of origin for this product is India.
