Microchip 8 Bit PIC Microcontroller PIC10F202T-I/OT, 4 MHz, 0.75kB FLASH, 6-Pin SOT-23
Specifications
| Country of Origin | India |
|---|---|
| Brand | Microchip |
| Height | 1.3mm |
| Length | 3.1mm |
| Model | PIC10F202T-I/OT |
| Width | 1.8mm |
| Mount Type | Surface |
| Series | PIC10 |
| Maximum Operating Temperature | 85°C |
| Package Type | SOT-23 |
| Minimum Operating Temperature | -40°C |
| Ram size | 24bit |
| Interface Type | SPI |
| Pin Count | 6 |
| Maximum Supply Voltage | 5.5V |
| Maximum Power Dissipation Pd | 800mW |
| Minimum Supply Voltage | 2V |
| Device Core | PIC |
| Program Memory Size | 0.75kB |
| Maximum Clock Frequency | 4MHz |
| Number of Programmable I/Os | 24 |
| Analogue Comparators | 2 |
| Number of Timers | 1 |
| Instruction Set Architecture | RISC |
| Program Memory Type | FLASH |
| Microchip, 8 bit PIC, PIC10 Microcontroller, 4 MHz FLASH, 6-Pin SOT-23Brand | Microchip |
Key Features
- Based on Microchip's original baseline PIC10F architecture.
- Operates at a maximum clock frequency of 4 MHz.
- Features 0.75kB FLASH program memory and 24 bit RAM size.
- Supplies SPI interface and 24 programmable I/Os.
- Works with a supply voltage range of 2 V to 5.5 V.
- Maximum power dissipation of 800 mW ensures energy efficiency.
- Operating temperature ranges from -40°C to 85°C for industrial reliability.
- Compact dimensions with 1.3 mm height, 3.1 mm length, and 1.8 mm width.
Product Description
Microchip PIC10F202T-I/OT is an 8 bit PIC microcontroller featuring an original PIC10F baseline architecture with up to 5 MIPs performance. It operates at a maximum clock frequency of 4 MHz and includes 0.75kB of FLASH program memory, suitable for compact embedded applications. The device is packaged in a 6-Pin SOT-23 surface mount package, designed for cost and space-sensitive environments.
Equipped with a SPI interface and 24 programmable I/O lines, this microcontroller supports versatile control and communication capabilities. It operates under a broad supply voltage range from 2 V to 5.5 V and offers a maximum power dissipation of 800 mW, making it energy efficient for various industrial, commercial, and consumer electronic applications.
The PIC10F202T includes two analogue comparators and one timer, expanding its capabilities for precise control and timing functions. Its operating temperature range from -40°C to 85°C ensures reliable operation in challenging ambient conditions.
This microcontroller’s compact dimensions of 3.1 mm length, 1.8 mm width, and 1.3 mm height suit it well for space-constrained designs on printed circuit boards. The device employs RISC instruction set architecture and integrates FLASH program memory technology for efficient programming and reprogramming.
Compact 6-Pin SOT-23 surface mount package. 0.75kB FLASH program memory for embedded control. Operates at up to 4 MHz clock frequency. Supports SPI interface and 24 programmable I/Os. Wide supply voltage range: 2 V to 5.5 V.
Maximum power dissipation of 800 mW for energy efficiency. Operating temperature range: -40°C to 85°C. Includes 2 analogue comparators and 1 timer.
This microcontroller is ideal for embedded electronics, industrial control systems, consumer electronics, and educational development projects requiring a low pin count solution. Its ultra-low cost, small footprint, and reliable performance make it a popular choice among engineers and designers.
Explore EnvMart’s extensive Microchip Microcontroller category for more embedded control options and accessories.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum clock frequency of this microcontroller is 4 MHz.
It features 0.75kB of FLASH program memory.
This microcontroller operates with a supply voltage range of 2 V to 5.5 V.
It includes 24 programmable I/O lines.
The operating temperature range is from -40°C to 85°C.
It is packaged in a 6-Pin SOT-23 surface mount package.
The dimensions are 3.1 mm in length, 1.8 mm in width, and 1.3 mm in height.
Yes, it supports a SPI interface.
The maximum power dissipation is 800 mW.
It employs a RISC instruction set architecture.
The RAM size is 24 bits.
