Texas Instruments DC/DC Power Supply Module 5-Channel 3 A 36V Input, 22V, 15V, 300 kHz, 7-Pin, DIP PTN78060HAH

Texas Instruments PTN78060HAH DC/DC Power Supply Module 5-Channel provides a compact, high-efficiency step-down (buck) switching voltage regulator solution designed for low-power applications where isolation is not required. It operates over a wide input voltage range of 15V to 36V and delivers up to 3A output current with an output voltage of 22.5V and total output power of 45W.

This module features a 7-pin DIP through-hole package and integrates a shielded inductor along with precision enable, soft-start, and tracking for sequencing. It provides best-in-class thermal performance and superior EMI protection, making it suitable for industrial, commercial, and laboratory electronic applications.

The PTN8060 series modules offer easy-to-use PCB mounting solutions that optimize space and efficiency. They are pin-to-pin compatible modules for different load currents, facilitating flexibility in design and implementation. The module complies with EN55022 (CISPR22) Class B standards for radiated and conducted EMI, ensuring electromagnetic compatibility in sensitive environments.

Operating temperature range spans from -40°C minimum up to 85°C maximum enabling use in a variety of environmental conditions. The module is ideal for use in power management circuits within industrial machines, measuring instruments, manufacturing equipment, and commercial electronic products.

Key technical specifications include a maximum switching frequency of 300 kHz, which allows for efficient and stable power conversion. The package height is 8.75 mm with a length of 25.27 mm, suitable for compact PCB layouts.

Overall, the Texas Instruments PTN78060HAH provides a reliable and efficient power supply solution for embedded and industrial DC/DC converter designs requiring compact size, robust performance, and compliance with international EMI standards.

The module supports a maximum switching frequency of 300 kHz for efficient power delivery. Equipped with a 7-pin DIP through-hole package type ensuring durable mounting. Operates reliably between minimum -40°C and maximum 85°C ambient temperatures.

Outputs 45W power with output voltages of 22.5V and input voltages ranging from 15V to 36V. The module series PTN8060 offers non-isolated step-down (buck) power modules optimized for PCB mounting. Designed with integrated shielded inductors that improve EMI protection and thermal management.

Pin-to-pin compatible with different load currents to suit various power requirements. Passes EN55022 (CISPR22) Class B radiated and conducted EMI standards for electromagnetic interference. Explore more power management ICs and DC-DC Power Supply Modules at EnvMart to find the best solution for your industrial and commercial electronic projects.
