Keystone 30A PCB Mount Fuse Holder 500V AC Nylon Body Tin Plated Brass Contacts 3522

Free Delivery in India | Lowest Global Shipping Charges

Keystone 30A PCB Mount Fuse Holder 500V AC Nylon Body Tin Plated Brass Contacts 3522

Name: Keystone 30A PCB Mount Fuse Holder 500V AC Nylon Body Tin Plated Brass Contacts 3522
Brand: Keystone
SKU: 148064
Price: 0.48 USD
Availability: InStock



Category Fuse Holders & Accessories Brand Keystone Condition New

Specifications

Country of Origin	United States
Brand	Keystone
Body Material	Nylon
Model	3522
Contact Material	Tin Plated Brass
Maximum Operating Temperature	145°C
Minimum Operating Temperature	-50°C
Standards/Approvals	UL Rated 94V-0, ISO 9002
Keystone 20A PCB Mount Fuse Holder, 500V acBrand	Keystone

Key Features

Vertical mount fuse holder suitable for single and double blade fuses.
Constructed with nylon body material and tin plated brass contacts.
Designed to withstand vibration and shock for reliable use.
Leg orientation ensures proper PCB installation with through-hole mount capability.
Compatible with wave soldering processes.
Maintains secure fuse hold after multiple insertions.
Features a space-saving low profile design for compact installations.
Maximum operating temperature of 145°C for high temperature applications.

Product Description

Keystone 3522 PCB Mount Fuse Holder is a 30 Ampere fuse holder with a voltage rating of 500V AC, designed to securely hold standard blade fuses in vertical mount configurations. It features a durable nylon body combined with tin plated brass contacts that ensure reliable conductivity and resistance to corrosion.

The fuse holder is engineered to withstand operating temperatures ranging from -50°C to 145°C, making it suitable for diverse industrial environments. Its shock and vibration resistance make it ideal for electronic assemblies requiring secure fuse retention under demanding conditions.

Its legs are specifically oriented for proper through-hole PCB mounting, facilitating reliable electrical connections during wave soldering processes and ensuring easy integration into printed circuit boards.

The low profile design conserves space on PCBs, while securely holding fuses firmly even after multiple insertions, enhancing maintenance and replacement efficiency.

The product meets UL Rated 94V-0 and ISO 9002 standards, assuring quality, safety, and consistent manufacturing processes. Its origin is the United States, reflecting stringent quality control.

Vertical mount fuse holder suitable for single and double blade fuses. Durable nylon body and tin plated brass contacts. Designed to withstand vibration and shock. Legs oriented for proper PCB mounting and wave soldering.

Secure fuse hold for multiple insertions. Space saving low profile design. Max operating temperature 145°C. UL Rated 94V-0, ISO 9002 certified.

This fuse holder is ideal for applications in electrical, automation, and circuit protection industries, particularly in PCB assemblies where reliable fuse mounting and thermal endurance are essential. For users seeking high-quality fuse holders meeting industrial standards, the Keystone 3522 model offers dependable performance in compact and durable form.
