Eaton xEffect Miniature Circuit Breaker, 1-Pole, 10A, Type S, 230V AC, 10 kA Breaking Capacity 278611 FAZ-S10/1
Specifications
| Country of Origin | India |
|---|---|
| Range | xEffect |
| Brand | Eaton |
| Model | 278611 FAZ-S10/1 |
| Depth | 74mm |
| IP Rating | IP20 |
| Width | 17.5mm |
| Mount Type | DIN Rail |
| Current Rating | 10A |
| Series | xEffect |
| Terminal type | Twin-Purpose Terminal |
| Breaking Capacity | 10kA |
| Number of Poles | 1 |
| Standards/Approvals | IEC/EN 60947-2 |
| Rated AC Voltage | 230V ac |
| Tripping Characteristics | Type S |
| Tripping Mechanism | Thermal Magnetic |
| Reset Actuator Type | Toggle Switch |
| Break Time | Instantaneous |
| MCB Module widths | 1P 17.5mm, 2P 35mm and 3P 52.5mm |
| 1 pole type S circuit breaker,6kA 10ABrand | Moeller |
Key Features
- Provides quick short-circuit interruption with a breaking capacity of 10 kA.
- Designed for use with 230V AC systems with a single pole configuration.
- Equipped with a toggle switch reset actuator and thermal magnetic tripping mechanism.
- Compact 17.5mm width enables space-saving DIN rail installation.
- Features twin-purpose terminal type and IP20 rating for finger protection.
- Complies with IEC/EN 60947-2 standards for electrical safety and performance.
- Includes a trip-free mechanism that prevents defeating by holding the handle in ON position.
- Suitable for electrical distribution boards and control circuits in industrial environment.
Product Description
Eaton 278611 FAZ-S10/1 miniature circuit breaker from the xEffect series is designed for overcurrent protection in electrical distribution and control systems. It features a thermal magnetic tripping mechanism offering instant response to overloads and short circuits.
Operating at a rated AC voltage of 230V, this single-pole device supports a current rating of 10A with a robust breaking capacity of 10 kA, ensuring enhanced safety and reliability in industrial, manufacturing, and commercial applications.
The compact 17.5mm width per pole and DIN rail mounting type allow for efficient panel space utilization. The breaker is equipped with a toggle switch reset actuator and twin-purpose terminals to facilitate ease of installation and maintenance.
Designed according to IEC/EN 60947-2 standards, the MCB is finger-proof with an IP20 rating, and incorporates a trip-free mechanism preventing bypass by holding the handle in the ON position. These features provide additional operational safety in electrical distribution boards.
The FAZ series delivers multiple short-circuit protection characteristic curves, with this model categorized under Type S, suitable for selective coordination in complex electrical networks.
Quick short-circuit interruption with a 10kA breaking capacity. Single-pole, 10A rated current for industrial electrical circuits. Toggle switch actuator with thermal magnetic tripping mechanism. Minimal 17.5mm modular width saves panel space.
DIN rail mounting and twin-purpose terminals for easy installation. Complies with IEC/EN 60947-2 safety standards. Trip-free mechanism ensures handle cannot be overridden. IP20 finger protection rating enhances user safety.
Compact 74mm depth for efficient panel integration. Suitable for use in electrical distribution boards and control circuits.
This Eaton Miniature Circuit Breaker is ideal for use in industrial automation, manufacturing facilities, commercial buildings, and HVAC systems requiring reliable circuit protection. Explore more high-quality circuit breakers and electrical safety solutions on EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has a breaking capacity of 10 kA, providing quick short-circuit interruption.
The Eaton FAZ-S10/1 has a rated current of 10A, suitable for various electrical applications.
It operates at a rated AC voltage of 230V, making it suitable for standard electrical systems.
The width of this miniature circuit breaker is 17.5mm, allowing for space-efficient installation on DIN rails.
This unit is designed for DIN rail mounting, facilitating easy installation in electrical panels.
It features a thermal magnetic tripping mechanism, which provides an instant response to overloads and short circuits.
The circuit breaker is equipped with twin-purpose terminals, enhancing installation flexibility.
This model has an IP20 rating, providing finger protection and ensuring safety during operation.
It complies with IEC/EN 60947-2 standards for electrical safety and performance.
The depth of this miniature circuit breaker is 74mm, allowing for efficient integration into panels.
The trip-free mechanism prevents the handle from being held in the ON position, ensuring safety during operation.
This circuit breaker is suitable for use in electrical distribution boards and control circuits in industrial environments.
