TRACOPOWER 2-Output 1W Surface Mount Isolated DC/DC Converter, 15V dc/ 33 mA Output, 13.2V dc Max Input, 10.8V Min TSM 1215D

TRACOPOWER TSM 1215D is a highly reliable isolated surface mount DC/DC converter designed to deliver 1 Watt of power with two outputs, including a 15V dc main output at 33mA current.

This converter operates with a maximum input voltage of 13.2V dc and a minimum input voltage of 10.8V, making it suitable for stable voltage conversion within this range. It achieves an efficiency rating of 80%, optimizing power consumption and thermal management.

The compact surface mount package measures 15.24mm in length, 8mm in width, and 7.8mm in depth, making it ideal for space-sensitive printed circuit board designs. Its isolation voltage of 1 kV dc ensures robust electrical separation between input and output, benefitting noise reduction and ground loop mitigation in complex circuits.

Operating reliably between -40°C and +85°C, this device is engineered for industrial, electronic, and manufacturing environments requiring dependable DC power conversion. The device's construction in lead frame technology supports automated SMD assembly and is RoHS-compliant, suitable for lead-free soldering processes.

The TSM 1215D's MTBF rating of 2,000,000 hours provides assurance of long-term durability and consistent output. Its isolated dual outputs make it useful for digital interface power isolation and eliminating interference in sensitive electronic setups.

Applications include industrial control systems, instrumentation, data processing equipment, point of load power supplies, and embedded computing platforms requiring compact, noise-isolated DC power sources.

The converter offers 15V dc output voltage with a maximum input voltage of 13.2V dc and minimum voltage of 10.8V. Supports up to 33mA output current with two isolated outputs. Highly efficient with 80% conversion efficiency.

Built for surface mount PCB integration with small footprint. Wide operating temperature range from -40°C to +85°C ensures reliability. 1 kV dc isolation voltage enhances noise immunity and safety. 2,000,000 hours MTBF ensures long-lasting performance.

Lead frame construction and RoHS compliance for environmentally safe manufacturing. Ideal for power conversion, noise reduction, and ground loop elimination. Manufactured in Taiwan, Province Of China. Explore more high-quality DC/DC Converters available on EnvMart for industrial, electronics, and power supply applications.
