Hongfa Europe GMBH PCB Power Relay 24V DC Coil 10A SPST HF33F/024-HSL3F
Specifications
| Country of Origin | China |
|---|---|
| Brand | Hongfa Europe GMBH |
| Height | 15.3mm |
| Length | 20.5mm |
| Model | HF33F/024-HSL3F |
| Width | 10.2mm |
| Mount Type | PCB |
| Contact Material | Silver Alloy |
| Series | HF33F |
| Maximum Operating Temperature | 70°C |
| Contact Configuration | SPST |
| Minimum Operating Temperature | -40°C |
| Switching Current | 10A |
| Terminal type | PCB Terminal |
| Contact Resistance | 100mΩ |
| Standards/Approvals | RoHS |
| Coil Resistance | 1280Ω |
| Coil Voltage | 24V dc |
| Switching DC Voltage | 30V dc |
| Switching AC Voltage | 250V ac |
| Coil Power | 200mW |
Key Features
- Operates with a coil voltage of 24V DC.
- Single-pole, single-throw (SPST) contact configuration suitable for PCB mounting.
- Supports switching AC voltage up to 250V and DC voltage up to 30V.
- Designed for high power switching with a coil power of 200mW.
- Compact relay with dimensions of 20.5mm length, 10.2mm width, and 15.3mm height.
- Silver alloy contact material ensures reliable and durable contact performance.
- Wide operating temperature range from -40°C to 70°C for diverse environments.
- Contact resistance of 100mΩ minimizes energy loss during switching.
Product Description
Hongfa Europe GMBH HF33F/024-HSL3F PCB Power Relay is a high-quality signal relay designed for reliable switching in industrial and electronic applications. Bringing a coil voltage of 24V DC and a switching current capacity of 10A, it supports single-pole single-throw (SPST) contact configuration ideal for PCB mounting. This sub-miniature intermediate power relay has a low mounting height of 15.3mm, with compact dimensions measuring 20.5mm in length and 10.2mm in width, allowing for integration in space-constrained circuits.
The relay features a silver alloy contact material which ensures long-term durability and low contact resistance of 100mΩ, providing minimal power loss. The coil resistance is 1280Ω and coil power rating of 200mW, contributing to its energy-efficient operation. It offers wide operating temperature tolerance ranging from -40°C to 70°C, enabling usage in harsh industrial, automotive, telecommunications, household appliance, and medical equipment environments.
This signal relay adheres to RoHS standards, affirming its environmental compliance. Its 10kV isolation voltage between coil and contact adds enhanced safety for sensitive electronic circuits. Its durability rating extends up to 5 million cycles, making it a trustworthy choice for robust switching needs.
Common applications include automotive engines, industrial machinery, medical instrumentation, and telecommunication equipment where reliable signal control and power switching at 10A current are critical.
Operates reliably from -40°C to 70°C. Compact and space-saving design for PCB mounting. Environmentally compliant RoHS product. High isolation voltage and durability rating of up to 5 million cycles. Silver alloy contacts for enhanced conductivity and reliability.
Choose the Hongfa Europe GMBH HF33F/024-HSL3F relay for dependable performance in your electrical and automation projects. Explore more Power Relay options and technical details on EnvMart for your industrial requirements.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The relay operates with a coil voltage of 24V DC.
It supports a maximum switching current of 10A.
This model has dimensions of 20.5mm in length, 10.2mm in width, and 15.3mm in height.
It features a single-pole, single-throw (SPST) contact configuration.
It can switch AC voltage up to 250V and DC voltage up to 30V.
The contact material is made of silver alloy, which ensures reliable performance.
The coil resistance is 1280Ω.
The coil power rating is 200mW.
It operates within a temperature range of -40°C to 70°C.
It has a durability rating of up to 5 million cycles.
Yes, this relay adheres to RoHS standards, affirming its environmental compliance.
It is designed for PCB mounting.
